Penjelasan Ringkas

We as the main distributor of the J-FLEX RUBBER PRODUCTS, England, by selling specialised rubber sheet rubber products & component engineering,

with the profile into its component parts: Seal for hydraulic-Pneumatic cylinder, flexibles consists of: Rubber Connections, Discharge socks, Gaiters, Bellows, cones , tubes, Flange sleeve, Covers, ballast bags, Vulcanised joint rings, Expansion joints, Sleeves Rubbers, gaskets, Diaphragms, washers,

His material consists of:
Red, White, translucent, Blue, black silicone rubber 60 ' shore, sheeting
Blue FDA, FDA translucent Slicone, Milky White Fda silicone, Red Silicone Fda, Yellow Silicone Fda Rubber 60 " shore, sheeting
Food Quality Translucent Silicone Rubber Sheeting 40' Shore A
Silicone Rubber 10' Shore A
" HTM" Light Green Thermally Conductive Silicone Sponge
Closed Cell Silicone White sponge sheeting, Closed Cell Silicone white Sponge Fda.
Red Iron Oxide Silicone Reinforced With 1 Ply Glass Cloth Insertion Sheet Fda.
Blue ( Nearest Pantone - 2955U) Metal Detectable Silicone Sheet Fda Compliant
Black gunuine DuPont Viton sheet 75 ' shore.
White FDA viton sheet 65 ' Shore
Nitriles / Nylon Sheet diaphragm
Neoprene / Nylon diaphragm sheet
Nitriles PVC / Nylon Floating Roof Tank Seals
Seat Valve Blue silicone Fda, Seat Valve Red Silicone Fda, Seat Valve Milky White Silicone Fda
EPDM 65 ' Shore
Viton Sheet
Viton sponge sheet

Market Sectors including:
Materials handing, Parmaceutical, Dry & Wet cement manufacturers, vibratory Motors, Offshore Oil, Food Processing, Dairy Industry, Animal feed stuffs, Agro-Chemical fertilizer, Pottery & ceramic, beverage production, Woodworking / Dust extraction, power plants, Test fasilities, marine engineering, Transportation, Environmetal Control, water engineering, textile machinery, paper machinery, Hydraulic engineering

Other products that we marketed:
One part caulk sealant Fluorodyn
Fluorolast solvent based coating ( Self-curing type)
Flurolast water borne coating ( head curable)
viton rubber coated product

We Al Nazeer Nippon Chemicals are the manufacturers and exporters of Elfy brand adhesives and sealants, our product range includes :
1.Super Glue

2.Silicone Sealants

3.RTV. Gasketmakers

4.Epoxy steel / clear Adhesives

Pump Sealing Technology Product by Slade USA:
Why Traditional Packings Fail

How a Stuffing Box Should Look When Completely Packed Using Traditional Packings
How a Stuffing Box Looks After Several Gland Adjustments Using Traditional Packings
Traditional packings are mostly fiber with added lubricants that can be squeezed, cooked or washed out, resulting in out-of position lantern rings, over-compressed packing and sleeve wear.

Slade Packed Centrifugal Pumps: Typical Stuffing Box VERSES Slade Packed Stuffing Box
Typical Stuffing Box: A typical stuffing box requires leakage and/ or flush-water to dissipate heat, creating costly housekeeping problems, loss of product and/ or loss of flush-water. Additional rings cannot be added without affecting position of lantern ring.

Slade Packed Stuffing Box: In most applications, a Slade packed stuffing box can be run without flush-water and/ or with virtually no leakage. In many applications, both No-Flush & No-Leak are possible! Additional rings can be added as needed.
Flush-Free & Virtual Leak-Free Service
slade packed stuffing boxDepending on design of equipment and speed of shaft, a permanent split bushing may be installed last ( after 3300G Rings) . Please contact us for a recommendation.

Seals Rotating Equipment:

Whereas most pump packings are largely abrasive fibers with added lubricants that can be squeezed, washed or cooked out, Slade 3300G utilizes the self-lubricating qualities of the very best natural, exfoliated graphite.

Incorporating just enough temperature and chemical resistant  carbon fiber to make very high tensile strength yarns, Slade s patented technology allows the braided packing rings to transfer frictional heat away from high speed shaft sleeves, eliminating the need, in most cases, for cooling water.

Since cooling or flushing is not typically required, there is no need for lantern rings. This eliminates the concern of the lantern rings being adjusted out of position, flush water ports becoming plugged, or sleeve wear caused by the corrosive nature of highly oxygenated water on hardened sleeves.

Pump Applications
For Steam, Nuclear and Hydro-Electric Plants

Boiler Feed Water
Boiler Recirculation
Condensate Pumps
Service Water Pumps
River Water Intake
Heater Drain Pumps
Vacuum Pumps
Clinker Grinders
Fly-Ash Pumps
Lime Slurry pumps
Auxiliary Feed-Water
Fire Pumps

For Pulp and Paper Mills

Refiners
Pulpers
Separators
Deflakers
Stock Pumps
Coating Pumps
Vacuum Pumps
Agitators
Condensate Pumps
Boiler Feed Pumps
Boiler Recirculation Pumps
Stock Chests
Mixers
Steam Vessels
Liquor Pumps
Outlet Devices

Product Information :

3300C Type:
Slade s Cost Effective Pump and Valve Packing
Reinforcement: Each yarn of graphite foil is reinforced with high strength structural carbon fiber
Temp:
Mild Oxidizers to 1800 F/ 1000 C ( for temperatures over 1000 F/ 540 C, consult the factory)
Pressures:
Valves to 1000 PSI/ 70 BAR ( for higher pressures, consult factory)
pH Range: 1-14
3300W Type:
Inconel wire reinforced for higher pressures: 5000 PSI/ 350 BAR
3300LC Type: Low chloride, high purity for nuclear service
3300LS Type: Low sulfur, high purity for nuclear service

3300G Type:
Slade s Best All Purpose Pump and Valve Packing
Reinforcement: Corners and yarns of graphite foil reinforced with high strength structural carbon fiber
Temp: Mild Oxidizers to 1800 F/ 1000 C ( for temperatures over 1000 F/ 540 C, consult the factory)
Pressures: Valves to 5000 PSI/ 350 BAR without end-rings
Pumps: Flush-free in many services to 4800 FPM ( 1400 m/ min)
pH Range: 1-14
Applications: Chemicals, steam, hydrocarbons, etc.
Advantages:

One packing inventory for all pumps and valves
Works well on worn sleeves
Difficult to overtighten
No added lubricants to squeeze out or burn off
Eliminates flush-water in most applications
Not necessary to replace entire set, just add ring
Won t glaze or harden
Eliminates most leaks
Amperage reduction of 15% is typical
No special end-rings required
Outlasts typical packings by factor of 6
4800 fpm/ 24 ms ( without flush water)
pH 1-14
Operates virtually leak-free in most applications
Low chloride/ sulfur available for nuclear service

Installation:

Check clearances and dimensions
Best to use no more than 5 rings in stuffing box ( use Slade spacer bushings to reduce rings)
Cut rings on the bias ( 45 angle) , stagger joints
Compress each sealing ring at least 25% ( especially the first ring) . Do not compress spacer bushings.
Loosen gland to allow it to relax
Snug the gland bolts and start the pump

3300GLC Type: Low chloride for nuclear service
3300GLS Type: Low sulfur for nuclear service

3300K Type:
Slades Best Triplex Pump, Reciprocating Packing
Reinforcement: Same as 3300C, but with added Kevlar fiber corners
Temp: Maximum temperature of 500 F/ 260 C
Applications: Reciprocating/ plunger, wastewater, steam and ammonia pumps
Pressures: 5000 PSI/ 350 BAR
pH Range 2-12
3300CJ Type:
Slade s Anti-Extrusion Carbon Fiber Packing
Description: Carbon jacketed 3300C
Pressures: Valves to 1000 PSI/ 70 BAR ( for higher pressures, consult factory)
Application: Used as anti-extrusion end-ring
3300CJK Type:
Slade s Anti-Extrusion Carbon Fiber Packing
Description: 3300C with Kevlar corners
Temp: 500 F/ 260 C
Application: Used as end-ring to provide anti-extrusion ( especially with large throat clearances) and to provide barrier to particulate contamination

Advantages:
Minimizes or Virtually Eliminates Leakage!
Due to its patented construction of natural, expanded graphite yarns, Slade 3300G turns the stuffing box into a heat sink, conducting heat away from shaft, in many applications, eliminating expensive leakage previously needed to cool the stuffing box.

Can Be Operated Flush-Free in Most Applications
Slade 3300G conducts heat away from the shaft/ sleeve, in most cases making flush unnecessary. If media has particulate contamination, a very mild flush should be all that is required.

No flush-water translates into:
Exceptional savings, typically 1/ 2 cent per gallon, or $ 13, 000 annually ( U.S.) ( based on 5 GPM flush system)
No fear of flush-water system becoming plugged or experiencing loss of pressure

Reduces Inventory and Cost
By eliminating die-formed rings ( cut-rings work fine)
Handles most medias, 1-14 pH, eliminating many styles of packing
In many applications, no need to remove old packing, just add a ring
Lasts 4 to 6 times longer than traditional pump packings
Worn Shafts and Sleeves Easily Sealed
Conforms to the geometry of the stuffing box and shaft. Seals most worn sleeves.

Valve Sealing Technology
Applications:
Gate Valves
Globe Valves
Pinch Valves
Diaphram Valves
Needle Valves
Plug Valves
Butterfly Valves
Ball Valves
Check Valves
Relief Valves
Control Valves
Knife Valves

Product Selection:
3300C
3300G
3300W
3300CJ
Enviro-Foil Valve Spacer Bushing
Vapor Depositioned 3300G Valve Spacer Bushing

Product Information
3300C Type:
Slade s Cost Effective Pump and Valve Packing
Reinforcement: Each yarn of graphite foil is reinforced with high strength structural carbon fiber
Temp:
Mild Oxidizers to 1800 F/ 1000 C
( for temperatures over 1000 F/ 540 C, consult the factory)
Pressures: Valves to 1000 PSI/ 70 BAR ( for higher pressures, consult factory)
pH Range: 1-14
3300W: Inconel wire reinforced for higher pressures: 5000 PSI/ 350 BAR
3300LC: Low chloride, high purity for nuclear service
3300LS: Low sulfur, high purity for nuclear service

3300G Type:
Slade s Best All Purpose Pump and Valve Packing
Reinforcement: Corners and yarns of graphite foil reinforced with high strength structural carbon fiber
Temp:
Mild Oxidizers to 1800 F/ 1000 C ( for temperatures over 1000 F/ 540 C, consult the factory)
Pressures: Valves to 5000 PSI/ 350 BAR without end-rings
Pumps: Flush-free in many services to 4800 FPM ( 1400 m/ min)
pH Range: 1-14
Applications: Chemicals, steam, hydrocarbons, etc.
Advantages

Please click here to see the comprehensive list of advantages that 3300G has to offer.

Installation:
Check clearances and dimensions
Best to use no more than 5 rings in stuffing box ( use Slade spacer bushings to reduce rings)
Cut rings on the bias ( 45 angle) , stagger joints
Compress each sealing ring at least 25% ( especially the first ring) . Do not compress spacer bushings.
Loosen gland to allow it to relax
Snug the gland bolts and start the pump

3300GLC: Low chloride for nuclear service
3300GLS: Low sulfur for nuclear service

3300W Type:
Slade' s Best Valve Packing
Reinforcement: Each yarn of graphite foil is reinforced with Inconel" Foil shrouded in high strength carbon fiber
Temp:
Mild oxidizers to 1800 F/ 1000 C ( for temperatures over 1000 F/ 540 C, consult the factory)
Pressures: Up to 5, 000 psi/ 345 psi

3300CJ Type:
Slade' s Anti-Extrusion Carbon Fiber Packing
Description: Carbon jacketed 3300C
Pressures: Valves to 1000 psi/ 70 bar ( for higher pressures, consult factory)
Application: Used as anti-extrusion end ring

Advantages:
Fire Safe
Slade braided graphite foil is API Fire Test Certified
API 589 First Edition
API 607 Fourth Edition ( modified by EXXON Specs)
Tested by Southwest Research Institute
Witnessed by 3 EXXON Engineers
Temperatures to 1800 F/ 1000 C
Tested at 5% of allowable standard
Performed under a grant from the American Petroleum Institute
Warning: Valves sealed with packings containing lubricants or blocking agents ( PTFE) may cause secondary fires when exposed to the intense heat of a fire in another unit, which would cause packing shrinkage and leakage of flammable fluids causing a secondary fire.
SLADE Patented Packings: rated FIRE SAFE

Emission Safe
PERF Emission Standards
Contact Slade for documentation
EXXON-Emission Report:
Emission tests, performed at a leading petroleum company' s test facility in Florham Park, NJ ( using PERF procedures and standards) , show that Slade patented, reinforced braided graphite foil outperformed standard die-formed graphite sealing rings.
Slade reduced emissions by 74% .
Corpus Report:
A major Gulf Coast, USA refinery reports that 96% of the 325 valves packed with slade reported zero ppm emissions. Most of these valves were packed in the field by inexperienced installers.
Cambridge Report:
A major USA West Coast refinery reports that after 5 years, 96% of the 282 field installed valves were at zero emissions and that the 3, 000 psi hydrogen control valves never went over 9 ppm during the 5 year test. Most of these valves were packed in the field.
All claims made herein are documented.

GASKET:

Pyro-Tex Woven Gasket Sheet Type:
A resilient, compressed sheet& that works!

Ready to be cut for use in severe conditions.

Services:
High temperatures ( for temperatures over 1000 F/ 540 C, consult the factory)
High pressures ( up to 4500 psi/ 310 bar)
High equipment wear ( scratches/ pores)

Reinforced with Flat Metal Leaf Springs( a) of stainless steel, encapsulated in a thick vermiculated graphite foil jacket ( b) . These metal reinforced graphite strands, Slade s weaving yarns, are woven into a tough, resilient cloth-like sheet ( c) .

The flat metal leaf springs at the core of each strand crisscross each other throughout the cloth to impart an enduring resiliency.

The woven sheets are compressed to increase density to form a leak tight gasket sheet.

Advantages
Flat metallic leaf springs, jacketed with graphite foil, make this 80 x 80 sheet the most resilient gasket you will need.
It takes physical abuse like no other graphite foil, handling and feeling like tough leather.
The metallic spring strands are woven across one another to actuate the gasket through each thermal cycle continually adjusting to expansion and contraction that leaves other compressed gasketing lifeless ( d) .
Pyro-Tex gasket sheet replaces spiral wound gaskets, removing the spiral leak path and eliminating the need for a compressing ring to prevent crushing.
Pyro-Tex gasket sheet puts flanges back in compliance by filling scratches, pores, and steam cuts with flexible graphite.
Each sheet is packed in heavy-duty tubes to eliminate shipping palettes and enable easy storage and handling.

Gasket Types:
Ring and Full Face
Manhole and Handhole
Diesel Exhaust Flange
Manifold
Combustion Engine Head
Turbine Crossover
Pressure Vessel
Heat Exchanger
Nuclear Service

Gasket Standard Sizes: Gasket Special Sizes:
80 x 80 60 x 60
3/ 32 ( nominal) 80 x any length

Pyro-Tex Joint Sealant Type:

Slade s self-forming gasket, the Pyro-Tex Joint Sealant, is made from patented graphite-foil encapsulated carbon-fiber reinforced yarns ( also available with stainless-steel foil yarns) . This self-forming gasket when in place is compressed to fit snugly. Available in 25 and 50 foot spools in various configurations, shapes, and thicknesses.

Change gasket without pulling tube bundles
Adhesive bonds in place during installation
Self forms into endless gasket
Made to virtually any thickness or width
Never hardens or dries out
Metallic reinforcement impedes extrusion
Readjustable, often re-usable
Individual strands reinforced with:
carbon fiber, 304 SS, or Inconel foil
Packaged on plastic spools
Inventory just one or two sizes
Eliminates the need to remove heat exchanger tubes from the shell

Performs better than:
Double jacketed metal gaskets
Spiral wound gaskets
Corrugated metal gaskets
More reliable than PTFE joint sealants
Eliminates large inventories
Easier to Handle
Stops damage from rough handling
Doesn' t kink out of shape
Adjusts to warped flanges
Fills pits and scratches up to 1/ 8" deep

Pressures
Stainless & Inconel versions, 4500psi
Carbon fiber version, low pressure services only

Temperatures
for temperatures over 1000 F/ 540 C, consult the factory

Chemical compatibility:
Consult Factory

Pyro-Tex Joint Sealant HP Type:

Pyro-Tex HP ( high-pressure) Joint Sealant is made from the same patented stainless-steel foil yarns as our sheet ( also available with carbon fiber reinforcement) . Available in 25 and 50 foot spools in various configurations, shapes, and thicknesses.

Change gasket without pulling tube bundles
Adhesive bonds in place during installation
Self forms into endless gasket
Made to virtually any thickness or width
Never hardens or dries out
Metallic reinforcement impedes extrusion
Readjustable, often re-usable
Individual strands reinforced with:
304 SS or Inconel foil
Packaged on plastic spools
Inventory just one or two sizes
Eliminates the need to remove heat exchanger tubes from the shell

Performs better than:
Double jacketed metal gaskets
Spiral wound gaskets
Corrugated metal gaskets
More reliable than TFE joint sealants
Eliminates large inventories
Easier to Handle
Stops damage from rough handling
Doesn' t kink out of shape
Adjusts to warped flanges
Fills pits and scratches up to 1/ 8" deep
Pressures
Stainless & Inconel versions 4500psi
Temperatures
( for temperatures over 1000 F/ 540 C, consult the factory)

Chemical compatibility:
Consult Factory

Industries Served:

Steam, Nuclear, and Hydro-Electric Plants :
Boiler Feed Water
Boiler Recirculation
Condensate Pumps
Service Water Pumps
River Water Intake
Heater Drain Pumps
Vacuum Pumps
Clinker Grinders
Fly-Ash Pumps
Lime Slurry pumps
Auxiliary Feed-Water
Fire Pumps

Pulp and Paper Mills:
Refiners
Pulpers
Separators
Deflakers
Stock Pumps
Coating Pumps
Vacuum Pumps
Agitators
Condensate
Boiler Feed Water
Boiler Recirculation
Liquor Pumps
Continuous Digester
Outlet Devices
High Pressure Feeder
Stock Chests

PetroChemical and Oil & Gas Refineries:
Hydrocarbon Pumps
Residual Pumps
Heat-Transfer Fluid Pumps ( Hot Oil)
Bottoms Pumps
Cooling Tower Pumps
Steam Turbines
Compressors
Molten Sulphur Pumps
Ammonia Pumps
Paraffin Extraction Pumps
Boiler Feed Pumps
Condensate Pumps
( many others)

Mining:
Water and Slurry Pumps

Boats/ Shipping:
Stern Tubes ( Tail Shafts)
Washdown Pumps
Fire Pumps
Saltwater Pumps
Bilge Water Pumps

Steel Manufacturing:
Water and Slurry Pumps

Sugar Refineries:
Raw Sugar Pumps
Juice Pumps
Syrup Pumps
Molasses Pumps
Vacuum Pumps

Distribution of product marketing area consists of:

CV.JAVATECH-SEAL Region City of Jakarta, Bogor, Depok, Tangerang, Bekasi( JABODETABEK) and surrounding areas, Indonesia

Address: Jl. Majapahit No.283, Depok II , Kota Depok, East Java
Telp : 021 7710074
Fax : 021 7710074
Contac person: Mrs. Cony Esther
Mobile: 081216641164
Email: techseals@ ymail.com
http: / / javatechseals.indonetwork.co.id

CV.Java Tech-Seal, Bandung Branch for Region Bandung City and surrounding areas, West Java, Indonesia

Address : Leuwigoong 104, Kota Cimahi - Jawa Barat ( Workshop )
Contac person: Mr. Rahadian Norowiyoso S.Si
Telp : 022 91791705
Mobile: 082347744243
Email: techseals@ ymail.com
http: / / javatechseals.indonetwork.co.id

Piramida Sakti Teknik, CV Region Yogyakarta, Solo, Semarang City and Surrounding Areas, Central Java, Indonesia
Address : Perum Puri Permata no.1A, Gunung Kunci, Kartasura-Solo, Central Java
Contac person: Mr.Deni Firmansyah SE.MM
Phone: 0271 784350
Fax : 0271 780059
Mobile: 081808092128; 085292647770
Email : techseals@ ymail.com

CV.Cahaya Seals and Gasket Region Malang City and Surrounding Areas, East Java, Indonesia

Address : Sulfat Garden D10, Jl. Simp Adi Sucipto Malang 65123
Contac person: Mr.Johan Dwi Wisnu, ST
Mobile: 08155522115

PT.Centra Indo Artha Region Kalimantan, Maluku, papua, and Surrounding Areas, Indonesia
Address : Kompleks Ruko Mega Grosir Cempaka Mas Blok D1-30
Jl. Let Jend Suprapto, Jakarta Pusat 10640
Telp 021 42888089
Fax: 021 33342111

Contac person: Mr.Johni Mende,
Mobile: 081311077763

CV.Java Tech-Seal, Luwuk Branch for Region Banggai and surrounding areas, Central Sulawesi , Indonesia

Address : BTN Pepabri Luwuk Banggai- Sulawesi Tengah
Contac person: Mr. Tony Samuel
Mobile: 0812 1664 1164
Email: techseals@ ymail.com
http: / / javatechseals.indonetwork.co.id

Produk Terbaru

Penawaran Jual

VALVE FOR INDUSTRY

Econosto UK Ltd supplies valves to industries all across the UK and Europe and as far afield as Australasia.

From the company’s inception in 1984 as Ball Valves UK Ltd a strategy of maintaining stock at levels that allowed rapid delivery of items normally associated with long lead times, ensured the company’s place as a leader in the market. In 1998 the company was acquired by the Dutch Econosto Group as an integral part of its Flow and Sealing Technology division.

The acquisition brought an array of complementary products and cost-effective own-brand ranges to the existing portfolio of quality, globally-recognised brands. In 2006 the company reflected this wider offering by changing its name to Econosto UK Ltd. In 2008 the Econosto Group was acquired by the ERIKS group nv as part of their strategy to strengthen

their valve division, particularly in the UK. This development again opened up wider opportunities and new markets for Econosto UK Ltd.

Products, Services and Markets Econosto UK serves a full range of markets across the globe which include the oil and gas industries, processing, marine, energy, pharmaceuticals and water industry selling to OEM’s, contractors, end-users and other distributors.

• Ball valves

• Gate, globe and check valves

• Butterfly valves

• Marine valves

• Related equipment and instrumentation

• Actuation, seal changes, drilling and other modifications, painting or special finishes all available

• Cleaning, pressure or temperature testing, nondestructive examination and PMI testing services

• Special products can be manufactured to precise customer requirements



Ball Valves

Ball valves take a lead role in the valve industry and

have wide-ranging applications. The high flow

capacity coupled with being very simple to

mechanise makes ball valves ideal for many

applications where an open/close facility is required

but not regulating of flow. Standard fittings can be

modified to a customer’s specification and they are

easy-to-use and virtually maintenance free.

Econosto UK supplies ball valves for all uses ranging

from brass valves for use with water to flanged

stainless steel for use with corrosive media.

Modified or special valves can be supplied on

request.

General Ball Valves

1 & 2 piece in Bronze, Brass, Carbon and Stainless Steels Wafer Pattern

Multi-Port, 3 & 4 way Flanged Floating Ball Valves Cast iron, Stainless and Carbon steel (incl. low temperature options) from stock Special alloys

Available 1/2”-16”, ANSI 150-600 and DIN Flanges Firesafe NACE

Soft & Metal Seated

Detail Produk »

We as the main distributor of the J-FLEX RUBBER PRODUCTS, England, by selling specialised rubber sheet rubber products & component engineering, with the profile into its component parts: Seal for hydraulic-Pneumatic cylinder, flexibles consists of: Rubber Connections, Discharge socks, Gaiters, Bellows, cones , tubes, Flange sleeve, Covers, ballast bags, Vulcanised joint rings, Expansion joints, Sleeves Rubbers, gaskets, Diaphragms, washers, His material consists of: Red, White, translucent, Blue, black silicone rubber 60 ' shore, sheeting Blue FDA, FDA translucent Slicone, Milky White Fda silicone, Red Silicone Fda, Yellow Silicone Fda Rubber 60 " shore, sheeting Food Quality Translucent Silicone Rubber Sheeting 40' Shore A Silicone Rubber 10' Shore A " HTM" Light Green Thermally Conductive Silicone Sponge Closed Cell Silicone White sponge sheeting, Closed Cell Silicone white Sponge Fda. Red Iron Oxide Silicone Reinforced With 1 Ply Glass Cloth Insertion Sheet Fda. Blue ( Nearest Pantone - 2955U) Metal Detectable Silicone Sheet Fda Compliant Black gunuine DuPont Viton sheet 75 ' shore. White FDA viton sheet 65 ' Shore Nitriles / Nylon Sheet diaphragm Neoprene / Nylon diaphragm sheet Nitriles PVC / Nylon Floating Roof Tank Seals Seat Valve Blue silicone Fda, Seat Valve Red Silicone Fda, Seat Valve Milky White Silicone Fda EPDM 65 ' Shore Viton Sheet Viton sponge sheet Market Sectors including: Materials handing, Parmaceutical, Dry & Wet cement manufacturers, vibratory Motors, Offshore Oil, Food Processing, Dairy Industry, Animal feed stuffs, Agro-Chemical fertilizer, Pottery & ceramic, beverage production, Woodworking / Dust extraction, power plants, Test fasilities, marine engineering, Transportation, Environmetal Control, water engineering, textile machinery, paper machinery, Hydraulic engineering Other products that we marketed: One part caulk sealant Fluorodyn Fluorolast solvent based coating ( Self-curing type) Flurolast water borne coating ( head curable) viton rubber coated product We Al Nazeer Nippon Chemicals are the manufacturers and exporters of Elfy brand adhesives and sealants, our product range includes : 1.Super Glue 2.Silicone Sealants 3.RTV. Gasketmakers 4.Epoxy steel / clear Adhesives Pump Sealing Technology Product by Slade USA: Why Traditional Packings Fail How a Stuffing Box Should Look When Completely Packed Using Traditional Packings How a Stuffing Box Looks After Several Gland Adjustments Using Traditional Packings Traditional packings are mostly fiber with added lubricants that can be squeezed, cooked or washed out, resulting in out-of position lantern rings, over-compressed packing and sleeve wear. Slade Packed Centrifugal Pumps: Typical Stuffing Box VERSES Slade Packed Stuffing Box Typical Stuffing Box: A typical stuffing box requires leakage and/ or flush-water to dissipate heat, creating costly housekeeping problems, loss of product and/ or loss of flush-water. Additional rings cannot be added without affecting position of lantern ring. Slade Packed Stuffing Box: In most applications, a Slade packed stuffing box can be run without flush-water and/ or with virtually no leakage. In many applications, both No-Flush & No-Leak are possible! Additional rings can be added as needed. Flush-Free & Virtual Leak-Free Service slade packed stuffing boxDepending on design of equipment and speed of shaft, a permanent split bushing may be installed last ( after 3300G Rings) . Please contact us for a recommendation. Seals Rotating Equipment: Whereas most pump packings are largely abrasive fibers with added lubricants that can be squeezed, washed or cooked out, Slade 3300G utilizes the self-lubricating qualities of the very best natural, exfoliated graphite. Incorporating just enough temperature and chemical resistant  carbon fiber to make very high tensile strength yarns, Slade s patented technology allows the braided packing rings to transfer frictional heat away from high speed shaft sleeves, eliminating the need, in most cases, for cooling water. Since cooling or flushing is not typically required, there is no need for lantern rings. This eliminates the concern of the lantern rings being adjusted out of position, flush water ports becoming plugged, or sleeve wear caused by the corrosive nature of highly oxygenated water on hardened sleeves. Pump Applications For Steam, Nuclear and Hydro-Electric Plants Boiler Feed Water Boiler Recirculation Condensate Pumps Service Water Pumps River Water Intake Heater Drain Pumps Vacuum Pumps Clinker Grinders Fly-Ash Pumps Lime Slurry pumps Auxiliary Feed-Water Fire Pumps For Pulp and Paper Mills Refiners Pulpers Separators Deflakers Stock Pumps Coating Pumps Vacuum Pumps Agitators Condensate Pumps Boiler Feed Pumps Boiler Recirculation Pumps Stock Chests Mixers Steam Vessels Liquor Pumps Outlet Devices Product Information : 3300C Type: Slade s Cost Effective Pump and Valve Packing Reinforcement: Each yarn of graphite foil is reinforced with high strength structural carbon fiber Temp: Mild Oxidizers to 1800 F/ 1000 C ( for temperatures over 1000 F/ 540 C, consult the factory) Pressures: Valves to 1000 PSI/ 70 BAR ( for higher pressures, consult factory) pH Range: 1-14 3300W Type: Inconel wire reinforced for higher pressures: 5000 PSI/ 350 BAR 3300LC Type: Low chloride, high purity for nuclear service 3300LS Type: Low sulfur, high purity for nuclear service 3300G Type: Slade s Best All Purpose Pump and Valve Packing Reinforcement: Corners and yarns of graphite foil reinforced with high strength structural carbon fiber Temp: Mild Oxidizers to 1800 F/ 1000 C ( for temperatures over 1000 F/ 540 C, consult the factory) Pressures: Valves to 5000 PSI/ 350 BAR without end-rings Pumps: Flush-free in many services to 4800 FPM ( 1400 m/ min) pH Range: 1-14 Applications: Chemicals, steam, hydrocarbons, etc. Advantages: One packing inventory for all pumps and valves Works well on worn sleeves Difficult to overtighten No added lubricants to squeeze out or burn off Eliminates flush-water in most applications Not necessary to replace entire set, just add ring Won t glaze or harden Eliminates most leaks Amperage reduction of 15% is typical No special end-rings required Outlasts typical packings by factor of 6 4800 fpm/ 24 ms ( without flush water) pH 1-14 Operates virtually leak-free in most applications Low chloride/ sulfur available for nuclear service Installation: Check clearances and dimensions Best to use no more than 5 rings in stuffing box ( use Slade spacer bushings to reduce rings) Cut rings on the bias ( 45 angle) , stagger joints Compress each sealing ring at least 25% ( especially the first ring) . Do not compress spacer bushings. Loosen gland to allow it to relax Snug the gland bolts and start the pump 3300GLC Type: Low chloride for nuclear service 3300GLS Type: Low sulfur for nuclear service 3300K Type: Slades Best Triplex Pump, Reciprocating Packing Reinforcement: Same as 3300C, but with added Kevlar fiber corners Temp: Maximum temperature of 500 F/ 260 C Applications: Reciprocating/ plunger, wastewater, steam and ammonia pumps Pressures: 5000 PSI/ 350 BAR pH Range 2-12 3300CJ Type: Slade s Anti-Extrusion Carbon Fiber Packing Description: Carbon jacketed 3300C Pressures: Valves to 1000 PSI/ 70 BAR ( for higher pressures, consult factory) Application: Used as anti-extrusion end-ring 3300CJK Type: Slade s Anti-Extrusion Carbon Fiber Packing Description: 3300C with Kevlar corners Temp: 500 F/ 260 C Application: Used as end-ring to provide anti-extrusion ( especially with large throat clearances) and to provide barrier to particulate contamination Advantages: Minimizes or Virtually Eliminates Leakage! Due to its patented construction of natural, expanded graphite yarns, Slade 3300G turns the stuffing box into a heat sink, conducting heat away from shaft, in many applications, eliminating expensive leakage previously needed to cool the stuffing box. Can Be Operated Flush-Free in Most Applications Slade 3300G conducts heat away from the shaft/ sleeve, in most cases making flush unnecessary. If media has particulate contamination, a very mild flush should be all that is required. No flush-water translates into: Exceptional savings, typically 1/ 2 cent per gallon, or $ 13, 000 annually ( U.S.) ( based on 5 GPM flush system) No fear of flush-water system becoming plugged or experiencing loss of pressure Reduces Inventory and Cost By eliminating die-formed rings ( cut-rings work fine) Handles most medias, 1-14 pH, eliminating many styles of packing In many applications, no need to remove old packing, just add a ring Lasts 4 to 6 times longer than traditional pump packings Worn Shafts and Sleeves Easily Sealed Conforms to the geometry of the stuffing box and shaft. Seals most worn sleeves. Valve Sealing Technology Applications: Gate Valves Globe Valves Pinch Valves Diaphram Valves Needle Valves Plug Valves Butterfly Valves Ball Valves Check Valves Relief Valves Control Valves Knife Valves Product Selection: 3300C 3300G 3300W 3300CJ Enviro-Foil Valve Spacer Bushing Vapor Depositioned 3300G Valve Spacer Bushing Product Information 3300C Type: Slade s Cost Effective Pump and Valve Packing Reinforcement: Each yarn of graphite foil is reinforced with high strength structural carbon fiber Temp: Mild Oxidizers to 1800 F/ 1000 C ( for temperatures over 1000 F/ 540 C, consult the factory) Pressures: Valves to 1000 PSI/ 70 BAR ( for higher pressures, consult factory) pH Range: 1-14 3300W: Inconel wire reinforced for higher pressures: 5000 PSI/ 350 BAR 3300LC: Low chloride, high purity for nuclear service 3300LS: Low sulfur, high purity for nuclear service 3300G Type: Slade s Best All Purpose Pump and Valve Packing Reinforcement: Corners and yarns of graphite foil reinforced with high strength structural carbon fiber Temp: Mild Oxidizers to 1800 F/ 1000 C ( for temperatures over 1000 F/ 540 C, consult the factory) Pressures: Valves to 5000 PSI/ 350 BAR without end-rings Pumps: Flush-free in many services to 4800 FPM ( 1400 m/ min) pH Range: 1-14 Applications: Chemicals, steam, hydrocarbons, etc. Advantages Please click here to see the comprehensive list of advantages that 3300G has to offer. Installation: Check clearances and dimensions Best to use no more than 5 rings in stuffing box ( use Slade spacer bushings to reduce rings) Cut rings on the bias ( 45 angle) , stagger joints Compress each sealing ring at least 25% ( especially the first ring) . Do not compress spacer bushings. Loosen gland to allow it to relax Snug the gland bolts and start the pump 3300GLC: Low chloride for nuclear service 3300GLS: Low sulfur for nuclear service 3300W Type: Slade' s Best Valve Packing Reinforcement: Each yarn of graphite foil is reinforced with Inconel" Foil shrouded in high strength carbon fiber Temp: Mild oxidizers to 1800 F/ 1000 C ( for temperatures over 1000 F/ 540 C, consult the factory) Pressures: Up to 5, 000 psi/ 345 psi 3300CJ Type: Slade' s Anti-Extrusion Carbon Fiber Packing Description: Carbon jacketed 3300C Pressures: Valves to 1000 psi/ 70 bar ( for higher pressures, consult factory) Application: Used as anti-extrusion end ring Advantages: Fire Safe Slade braided graphite foil is API Fire Test Certified API 589 First Edition API 607 Fourth Edition ( modified by EXXON Specs) Tested by Southwest Research Institute Witnessed by 3 EXXON Engineers Temperatures to 1800 F/ 1000 C Tested at 5% of allowable standard Performed under a grant from the American Petroleum Institute Warning: Valves sealed with packings containing lubricants or blocking agents ( PTFE) may cause secondary fires when exposed to the intense heat of a fire in another unit, which would cause packing shrinkage and leakage of flammable fluids causing a secondary fire. SLADE Patented Packings: rated FIRE SAFE Emission Safe PERF Emission Standards Contact Slade for documentation EXXON-Emission Report: Emission tests, performed at a leading petroleum company' s test facility in Florham Park, NJ ( using PERF procedures and standards) , show that Slade patented, reinforced braided graphite foil outperformed standard die-formed graphite sealing rings. Slade reduced emissions by 74% . Corpus Report: A major Gulf Coast, USA refinery reports that 96% of the 325 valves packed with slade reported zero ppm emissions. Most of these valves were packed in the field by inexperienced installers. Cambridge Report: A major USA West Coast refinery reports that after 5 years, 96% of the 282 field installed valves were at zero emissions and that the 3, 000 psi hydrogen control valves never went over 9 ppm during the 5 year test. Most of these valves were packed in the field. All claims made herein are documented. GASKET: Pyro-Tex Woven Gasket Sheet Type: A resilient, compressed sheet& that works! Ready to be cut for use in severe conditions. Services: High temperatures ( for temperatures over 1000 F/ 540 C, consult the factory) High pressures ( up to 4500 psi/ 310 bar) High equipment wear ( scratches/ pores) Reinforced with Flat Metal Leaf Springs( a) of stainless steel, encapsulated in a thick vermiculated graphite foil jacket ( b) . These metal reinforced graphite strands, Slade s weaving yarns, are woven into a tough, resilient cloth-like sheet ( c) . The flat metal leaf springs at the core of each strand crisscross each other throughout the cloth to impart an enduring resiliency. The woven sheets are compressed to increase density to form a leak tight gasket sheet. Advantages Flat metallic leaf springs, jacketed with graphite foil, make this 80 x 80 sheet the most resilient gasket you will need. It takes physical abuse like no other graphite foil, handling and feeling like tough leather. The metallic spring strands are woven across one another to actuate the gasket through each thermal cycle continually adjusting to expansion and contraction that leaves other compressed gasketing lifeless ( d) . Pyro-Tex gasket sheet replaces spiral wound gaskets, removing the spiral leak path and eliminating the need for a compressing ring to prevent crushing. Pyro-Tex gasket sheet puts flanges back in compliance by filling scratches, pores, and steam cuts with flexible graphite. Each sheet is packed in heavy-duty tubes to eliminate shipping palettes and enable easy storage and handling. Gasket Types: Ring and Full Face Manhole and Handhole Diesel Exhaust Flange Manifold Combustion Engine Head Turbine Crossover Pressure Vessel Heat Exchanger Nuclear Service Gasket Standard Sizes: Gasket Special Sizes: 80 x 80 60 x 60 3/ 32 ( nominal) 80 x any length Pyro-Tex Joint Sealant Type: Slade s self-forming gasket, the Pyro-Tex Joint Sealant, is made from patented graphite-foil encapsulated carbon-fiber reinforced yarns ( also available with stainless-steel foil yarns) . This self-forming gasket when in place is compressed to fit snugly. Available in 25 and 50 foot spools in various configurations, shapes, and thicknesses. Change gasket without pulling tube bundles Adhesive bonds in place during installation Self forms into endless gasket Made to virtually any thickness or width Never hardens or dries out Metallic reinforcement impedes extrusion Readjustable, often re-usable Individual strands reinforced with: carbon fiber, 304 SS, or Inconel foil Packaged on plastic spools Inventory just one or two sizes Eliminates the need to remove heat exchanger tubes from the shell Performs better than: Double jacketed metal gaskets Spiral wound gaskets Corrugated metal gaskets More reliable than PTFE joint sealants Eliminates large inventories Easier to Handle Stops damage from rough handling Doesn' t kink out of shape Adjusts to warped flanges Fills pits and scratches up to 1/ 8" deep Pressures Stainless & Inconel versions, 4500psi Carbon fiber version, low pressure services only Temperatures for temperatures over 1000 F/ 540 C, consult the factory Chemical compatibility: Consult Factory Pyro-Tex Joint Sealant HP Type: Pyro-Tex HP ( high-pressure) Joint Sealant is made from the same patented stainless-steel foil yarns as our sheet ( also available with carbon fiber reinforcement) . Available in 25 and 50 foot spools in various configurations, shapes, and thicknesses. Change gasket without pulling tube bundles Adhesive bonds in place during installation Self forms into endless gasket Made to virtually any thickness or width Never hardens or dries out Metallic reinforcement impedes extrusion Readjustable, often re-usable Individual strands reinforced with: 304 SS or Inconel foil Packaged on plastic spools Inventory just one or two sizes Eliminates the need to remove heat exchanger tubes from the shell Performs better than: Double jacketed metal gaskets Spiral wound gaskets Corrugated metal gaskets More reliable than TFE joint sealants Eliminates large inventories Easier to Handle Stops damage from rough handling Doesn' t kink out of shape Adjusts to warped flanges Fills pits and scratches up to 1/ 8" deep Pressures Stainless & Inconel versions 4500psi Temperatures ( for temperatures over 1000 F/ 540 C, consult the factory) Chemical compatibility: Consult Factory Industries Served: Steam, Nuclear, and Hydro-Electric Plants : Boiler Feed Water Boiler Recirculation Condensate Pumps Service Water Pumps River Water Intake Heater Drain Pumps Vacuum Pumps Clinker Grinders Fly-Ash Pumps Lime Slurry pumps Auxiliary Feed-Water Fire Pumps Pulp and Paper Mills: Refiners Pulpers Separators Deflakers Stock Pumps Coating Pumps Vacuum Pumps Agitators Condensate Boiler Feed Water Boiler Recirculation Liquor Pumps Continuous Digester Outlet Devices High Pressure Feeder Stock Chests PetroChemical and Oil & Gas Refineries: Hydrocarbon Pumps Residual Pumps Heat-Transfer Fluid Pumps ( Hot Oil) Bottoms Pumps Cooling Tower Pumps Steam Turbines Compressors Molten Sulphur Pumps Ammonia Pumps Paraffin Extraction Pumps Boiler Feed Pumps Condensate Pumps ( many others) Mining: Water and Slurry Pumps Boats/ Shipping: Stern Tubes ( Tail Shafts) Washdown Pumps Fire Pumps Saltwater Pumps Bilge Water Pumps Steel Manufacturing: Water and Slurry Pumps Sugar Refineries: Raw Sugar Pumps Juice Pumps Syrup Pumps Molasses Pumps Vacuum Pumps Distribution of product marketing area consists of: CV.JAVATECH-SEAL Region City of Jakarta, Bogor, Depok, Tangerang, Bekasi( JABODETABEK) and surrounding areas, Indonesia Address: Jl. Majapahit No.283, Depok II , Kota Depok, East Java Telp : 021 7710074 Fax : 021 7710074 Contac person: Mrs. Cony Esther Mobile: 081216641164 Email: techseals@ ymail.com http: / / javatechseals.indonetwork.co.id CV.Java Tech-Seal, Bandung Branch for Region Bandung City and surrounding areas, West Java, Indonesia Address : Leuwigoong 104, Kota Cimahi - Jawa Barat ( Workshop ) Contac person: Mr. Rahadian Norowiyoso S.Si Telp : 022 91791705 Mobile: 082347744243 Email: techseals@ ymail.com http: / / javatechseals.indonetwork.co.id Piramida Sakti Teknik, CV Region Yogyakarta, Solo, Semarang City and Surrounding Areas, Central Java, Indonesia Address : Perum Puri Permata no.1A, Gunung Kunci, Kartasura-Solo, Central Java Contac person: Mr.Deni Firmansyah SE.MM Phone: 0271 784350 Fax : 0271 780059 Mobile: 081808092128; 085292647770 Email : techseals@ ymail.com CV.Cahaya Seals and Gasket Region Malang City and Surrounding Areas, East Java, Indonesia Address : Sulfat Garden D10, Jl. Simp Adi Sucipto Malang 65123 Contac person: Mr.Johan Dwi Wisnu, ST Mobile: 08155522115 PT.Centra Indo Artha Region Kalimantan, Maluku, papua, and Surrounding Areas, Indonesia Address : Kompleks Ruko Mega Grosir Cempaka Mas Blok D1-30 Jl. Let Jend Suprapto, Jakarta Pusat 10640 Telp 021 42888089 Fax: 021 33342111 Contac person: Mr.Johni Mende, Mobile: 081311077763 CV.Java Tech-Seal, Luwuk Branch for Region Banggai and surrounding areas, Central Sulawesi , Indonesia Address : BTN Pepabri Luwuk Banggai- Sulawesi Tengah Contac person: Mr. Tony Samuel Mobile: 0812 1664 1164 Email: techseals@ ymail.com http: / / javatechseals.indonetwork.co.id
  • Kota Sidoarjo

Katalog Produk

TOOLS EGA MASTER

Alat Teknik Tangan Kami adalah salah satu stockiest terbesar dari semua jenis alat-alat tangan industri. Alat-alat tangan ini digunakan secara manual oleh karena itu mereka justru dirancang agar sesuai di tangan yang menyederhanakan perakitan, perbaikan, instalasi dan aplikasi industri lainnya. Kami seluruh rentang alat-alat tangan yang diproduksi mengkonfirmasikan kepada norma-norma industri yang ada sehingga memiliki pasar di seluruh dunia yang luas. Insulated Alat Organisasi kami sangat dihargai oleh klien untuk menawarkan alat Insulated. Dirancang dengan menggunakan bahan baku bermutu tinggi, alat-alat ini VDE -tested. Maskapai 1.000 volt tools & kit terisolasi diproduksi menggunakan bahan baku bermutu tinggi dan mesin canggih. Alat yang ditawarkan tersedia dalam berbagai ukuran yang sesuai dengan kebutuhan beragam klien.   tool Set Dealer dan importir dari Tool Kits untuk berbagai aplikasi industri. Baik itu lokakarya atau individu, kami dapat menawarkan tool kit untuk setiap aplikasi seperti Pemeliharaan, Listrik, Plumbing, HVAC, Rail Road dan Pesawat di merek terkenal. Berbagai alat kit yang kami tawarkan adalah 1. Guru Teknisi Pemeliharaan Set 2. Teknik Mesin Tool Set 3. Alat Listrik Kit 4. Electromechanical & Pelayanan Tool Set 5. Modular Set 6. Bantalan Penarik Set 7. Railroad Jalan Mechanic Set 8. motor Mechanic Tool Set 9. HVAC Tool Set 10. Plumber Tool Set 11. Kontraktor Tool Set 12. Electrician di Tool Set

Detail Produk »

We as the main distributor of the J-FLEX RUBBER PRODUCTS, England, by selling specialised rubber sheet rubber products & component engineering, with the profile into its component parts: Seal for hydraulic-Pneumatic cylinder, flexibles consists of: Rubber Connections, Discharge socks, Gaiters, Bellows, cones , tubes, Flange sleeve, Covers, ballast bags, Vulcanised joint rings, Expansion joints, Sleeves Rubbers, gaskets, Diaphragms, washers, His material consists of: Red, White, translucent, Blue, black silicone rubber 60 ' shore, sheeting Blue FDA, FDA translucent Slicone, Milky White Fda silicone, Red Silicone Fda, Yellow Silicone Fda Rubber 60 " shore, sheeting Food Quality Translucent Silicone Rubber Sheeting 40' Shore A Silicone Rubber 10' Shore A " HTM" Light Green Thermally Conductive Silicone Sponge Closed Cell Silicone White sponge sheeting, Closed Cell Silicone white Sponge Fda. Red Iron Oxide Silicone Reinforced With 1 Ply Glass Cloth Insertion Sheet Fda. Blue ( Nearest Pantone - 2955U) Metal Detectable Silicone Sheet Fda Compliant Black gunuine DuPont Viton sheet 75 ' shore. White FDA viton sheet 65 ' Shore Nitriles / Nylon Sheet diaphragm Neoprene / Nylon diaphragm sheet Nitriles PVC / Nylon Floating Roof Tank Seals Seat Valve Blue silicone Fda, Seat Valve Red Silicone Fda, Seat Valve Milky White Silicone Fda EPDM 65 ' Shore Viton Sheet Viton sponge sheet Market Sectors including: Materials handing, Parmaceutical, Dry & Wet cement manufacturers, vibratory Motors, Offshore Oil, Food Processing, Dairy Industry, Animal feed stuffs, Agro-Chemical fertilizer, Pottery & ceramic, beverage production, Woodworking / Dust extraction, power plants, Test fasilities, marine engineering, Transportation, Environmetal Control, water engineering, textile machinery, paper machinery, Hydraulic engineering Other products that we marketed: One part caulk sealant Fluorodyn Fluorolast solvent based coating ( Self-curing type) Flurolast water borne coating ( head curable) viton rubber coated product We Al Nazeer Nippon Chemicals are the manufacturers and exporters of Elfy brand adhesives and sealants, our product range includes : 1.Super Glue 2.Silicone Sealants 3.RTV. Gasketmakers 4.Epoxy steel / clear Adhesives Pump Sealing Technology Product by Slade USA: Why Traditional Packings Fail How a Stuffing Box Should Look When Completely Packed Using Traditional Packings How a Stuffing Box Looks After Several Gland Adjustments Using Traditional Packings Traditional packings are mostly fiber with added lubricants that can be squeezed, cooked or washed out, resulting in out-of position lantern rings, over-compressed packing and sleeve wear. Slade Packed Centrifugal Pumps: Typical Stuffing Box VERSES Slade Packed Stuffing Box Typical Stuffing Box: A typical stuffing box requires leakage and/ or flush-water to dissipate heat, creating costly housekeeping problems, loss of product and/ or loss of flush-water. Additional rings cannot be added without affecting position of lantern ring. Slade Packed Stuffing Box: In most applications, a Slade packed stuffing box can be run without flush-water and/ or with virtually no leakage. In many applications, both No-Flush & No-Leak are possible! Additional rings can be added as needed. Flush-Free & Virtual Leak-Free Service slade packed stuffing boxDepending on design of equipment and speed of shaft, a permanent split bushing may be installed last ( after 3300G Rings) . Please contact us for a recommendation. Seals Rotating Equipment: Whereas most pump packings are largely abrasive fibers with added lubricants that can be squeezed, washed or cooked out, Slade 3300G utilizes the self-lubricating qualities of the very best natural, exfoliated graphite. Incorporating just enough temperature and chemical resistant  carbon fiber to make very high tensile strength yarns, Slade s patented technology allows the braided packing rings to transfer frictional heat away from high speed shaft sleeves, eliminating the need, in most cases, for cooling water. Since cooling or flushing is not typically required, there is no need for lantern rings. This eliminates the concern of the lantern rings being adjusted out of position, flush water ports becoming plugged, or sleeve wear caused by the corrosive nature of highly oxygenated water on hardened sleeves. Pump Applications For Steam, Nuclear and Hydro-Electric Plants Boiler Feed Water Boiler Recirculation Condensate Pumps Service Water Pumps River Water Intake Heater Drain Pumps Vacuum Pumps Clinker Grinders Fly-Ash Pumps Lime Slurry pumps Auxiliary Feed-Water Fire Pumps For Pulp and Paper Mills Refiners Pulpers Separators Deflakers Stock Pumps Coating Pumps Vacuum Pumps Agitators Condensate Pumps Boiler Feed Pumps Boiler Recirculation Pumps Stock Chests Mixers Steam Vessels Liquor Pumps Outlet Devices Product Information : 3300C Type: Slade s Cost Effective Pump and Valve Packing Reinforcement: Each yarn of graphite foil is reinforced with high strength structural carbon fiber Temp: Mild Oxidizers to 1800 F/ 1000 C ( for temperatures over 1000 F/ 540 C, consult the factory) Pressures: Valves to 1000 PSI/ 70 BAR ( for higher pressures, consult factory) pH Range: 1-14 3300W Type: Inconel wire reinforced for higher pressures: 5000 PSI/ 350 BAR 3300LC Type: Low chloride, high purity for nuclear service 3300LS Type: Low sulfur, high purity for nuclear service 3300G Type: Slade s Best All Purpose Pump and Valve Packing Reinforcement: Corners and yarns of graphite foil reinforced with high strength structural carbon fiber Temp: Mild Oxidizers to 1800 F/ 1000 C ( for temperatures over 1000 F/ 540 C, consult the factory) Pressures: Valves to 5000 PSI/ 350 BAR without end-rings Pumps: Flush-free in many services to 4800 FPM ( 1400 m/ min) pH Range: 1-14 Applications: Chemicals, steam, hydrocarbons, etc. Advantages: One packing inventory for all pumps and valves Works well on worn sleeves Difficult to overtighten No added lubricants to squeeze out or burn off Eliminates flush-water in most applications Not necessary to replace entire set, just add ring Won t glaze or harden Eliminates most leaks Amperage reduction of 15% is typical No special end-rings required Outlasts typical packings by factor of 6 4800 fpm/ 24 ms ( without flush water) pH 1-14 Operates virtually leak-free in most applications Low chloride/ sulfur available for nuclear service Installation: Check clearances and dimensions Best to use no more than 5 rings in stuffing box ( use Slade spacer bushings to reduce rings) Cut rings on the bias ( 45 angle) , stagger joints Compress each sealing ring at least 25% ( especially the first ring) . Do not compress spacer bushings. Loosen gland to allow it to relax Snug the gland bolts and start the pump 3300GLC Type: Low chloride for nuclear service 3300GLS Type: Low sulfur for nuclear service 3300K Type: Slades Best Triplex Pump, Reciprocating Packing Reinforcement: Same as 3300C, but with added Kevlar fiber corners Temp: Maximum temperature of 500 F/ 260 C Applications: Reciprocating/ plunger, wastewater, steam and ammonia pumps Pressures: 5000 PSI/ 350 BAR pH Range 2-12 3300CJ Type: Slade s Anti-Extrusion Carbon Fiber Packing Description: Carbon jacketed 3300C Pressures: Valves to 1000 PSI/ 70 BAR ( for higher pressures, consult factory) Application: Used as anti-extrusion end-ring 3300CJK Type: Slade s Anti-Extrusion Carbon Fiber Packing Description: 3300C with Kevlar corners Temp: 500 F/ 260 C Application: Used as end-ring to provide anti-extrusion ( especially with large throat clearances) and to provide barrier to particulate contamination Advantages: Minimizes or Virtually Eliminates Leakage! Due to its patented construction of natural, expanded graphite yarns, Slade 3300G turns the stuffing box into a heat sink, conducting heat away from shaft, in many applications, eliminating expensive leakage previously needed to cool the stuffing box. Can Be Operated Flush-Free in Most Applications Slade 3300G conducts heat away from the shaft/ sleeve, in most cases making flush unnecessary. If media has particulate contamination, a very mild flush should be all that is required. No flush-water translates into: Exceptional savings, typically 1/ 2 cent per gallon, or $ 13, 000 annually ( U.S.) ( based on 5 GPM flush system) No fear of flush-water system becoming plugged or experiencing loss of pressure Reduces Inventory and Cost By eliminating die-formed rings ( cut-rings work fine) Handles most medias, 1-14 pH, eliminating many styles of packing In many applications, no need to remove old packing, just add a ring Lasts 4 to 6 times longer than traditional pump packings Worn Shafts and Sleeves Easily Sealed Conforms to the geometry of the stuffing box and shaft. Seals most worn sleeves. Valve Sealing Technology Applications: Gate Valves Globe Valves Pinch Valves Diaphram Valves Needle Valves Plug Valves Butterfly Valves Ball Valves Check Valves Relief Valves Control Valves Knife Valves Product Selection: 3300C 3300G 3300W 3300CJ Enviro-Foil Valve Spacer Bushing Vapor Depositioned 3300G Valve Spacer Bushing Product Information 3300C Type: Slade s Cost Effective Pump and Valve Packing Reinforcement: Each yarn of graphite foil is reinforced with high strength structural carbon fiber Temp: Mild Oxidizers to 1800 F/ 1000 C ( for temperatures over 1000 F/ 540 C, consult the factory) Pressures: Valves to 1000 PSI/ 70 BAR ( for higher pressures, consult factory) pH Range: 1-14 3300W: Inconel wire reinforced for higher pressures: 5000 PSI/ 350 BAR 3300LC: Low chloride, high purity for nuclear service 3300LS: Low sulfur, high purity for nuclear service 3300G Type: Slade s Best All Purpose Pump and Valve Packing Reinforcement: Corners and yarns of graphite foil reinforced with high strength structural carbon fiber Temp: Mild Oxidizers to 1800 F/ 1000 C ( for temperatures over 1000 F/ 540 C, consult the factory) Pressures: Valves to 5000 PSI/ 350 BAR without end-rings Pumps: Flush-free in many services to 4800 FPM ( 1400 m/ min) pH Range: 1-14 Applications: Chemicals, steam, hydrocarbons, etc. Advantages Please click here to see the comprehensive list of advantages that 3300G has to offer. Installation: Check clearances and dimensions Best to use no more than 5 rings in stuffing box ( use Slade spacer bushings to reduce rings) Cut rings on the bias ( 45 angle) , stagger joints Compress each sealing ring at least 25% ( especially the first ring) . Do not compress spacer bushings. Loosen gland to allow it to relax Snug the gland bolts and start the pump 3300GLC: Low chloride for nuclear service 3300GLS: Low sulfur for nuclear service 3300W Type: Slade' s Best Valve Packing Reinforcement: Each yarn of graphite foil is reinforced with Inconel" Foil shrouded in high strength carbon fiber Temp: Mild oxidizers to 1800 F/ 1000 C ( for temperatures over 1000 F/ 540 C, consult the factory) Pressures: Up to 5, 000 psi/ 345 psi 3300CJ Type: Slade' s Anti-Extrusion Carbon Fiber Packing Description: Carbon jacketed 3300C Pressures: Valves to 1000 psi/ 70 bar ( for higher pressures, consult factory) Application: Used as anti-extrusion end ring Advantages: Fire Safe Slade braided graphite foil is API Fire Test Certified API 589 First Edition API 607 Fourth Edition ( modified by EXXON Specs) Tested by Southwest Research Institute Witnessed by 3 EXXON Engineers Temperatures to 1800 F/ 1000 C Tested at 5% of allowable standard Performed under a grant from the American Petroleum Institute Warning: Valves sealed with packings containing lubricants or blocking agents ( PTFE) may cause secondary fires when exposed to the intense heat of a fire in another unit, which would cause packing shrinkage and leakage of flammable fluids causing a secondary fire. SLADE Patented Packings: rated FIRE SAFE Emission Safe PERF Emission Standards Contact Slade for documentation EXXON-Emission Report: Emission tests, performed at a leading petroleum company' s test facility in Florham Park, NJ ( using PERF procedures and standards) , show that Slade patented, reinforced braided graphite foil outperformed standard die-formed graphite sealing rings. Slade reduced emissions by 74% . Corpus Report: A major Gulf Coast, USA refinery reports that 96% of the 325 valves packed with slade reported zero ppm emissions. Most of these valves were packed in the field by inexperienced installers. Cambridge Report: A major USA West Coast refinery reports that after 5 years, 96% of the 282 field installed valves were at zero emissions and that the 3, 000 psi hydrogen control valves never went over 9 ppm during the 5 year test. Most of these valves were packed in the field. All claims made herein are documented. GASKET: Pyro-Tex Woven Gasket Sheet Type: A resilient, compressed sheet& that works! Ready to be cut for use in severe conditions. Services: High temperatures ( for temperatures over 1000 F/ 540 C, consult the factory) High pressures ( up to 4500 psi/ 310 bar) High equipment wear ( scratches/ pores) Reinforced with Flat Metal Leaf Springs( a) of stainless steel, encapsulated in a thick vermiculated graphite foil jacket ( b) . These metal reinforced graphite strands, Slade s weaving yarns, are woven into a tough, resilient cloth-like sheet ( c) . The flat metal leaf springs at the core of each strand crisscross each other throughout the cloth to impart an enduring resiliency. The woven sheets are compressed to increase density to form a leak tight gasket sheet. Advantages Flat metallic leaf springs, jacketed with graphite foil, make this 80 x 80 sheet the most resilient gasket you will need. It takes physical abuse like no other graphite foil, handling and feeling like tough leather. The metallic spring strands are woven across one another to actuate the gasket through each thermal cycle continually adjusting to expansion and contraction that leaves other compressed gasketing lifeless ( d) . Pyro-Tex gasket sheet replaces spiral wound gaskets, removing the spiral leak path and eliminating the need for a compressing ring to prevent crushing. Pyro-Tex gasket sheet puts flanges back in compliance by filling scratches, pores, and steam cuts with flexible graphite. Each sheet is packed in heavy-duty tubes to eliminate shipping palettes and enable easy storage and handling. Gasket Types: Ring and Full Face Manhole and Handhole Diesel Exhaust Flange Manifold Combustion Engine Head Turbine Crossover Pressure Vessel Heat Exchanger Nuclear Service Gasket Standard Sizes: Gasket Special Sizes: 80 x 80 60 x 60 3/ 32 ( nominal) 80 x any length Pyro-Tex Joint Sealant Type: Slade s self-forming gasket, the Pyro-Tex Joint Sealant, is made from patented graphite-foil encapsulated carbon-fiber reinforced yarns ( also available with stainless-steel foil yarns) . This self-forming gasket when in place is compressed to fit snugly. Available in 25 and 50 foot spools in various configurations, shapes, and thicknesses. Change gasket without pulling tube bundles Adhesive bonds in place during installation Self forms into endless gasket Made to virtually any thickness or width Never hardens or dries out Metallic reinforcement impedes extrusion Readjustable, often re-usable Individual strands reinforced with: carbon fiber, 304 SS, or Inconel foil Packaged on plastic spools Inventory just one or two sizes Eliminates the need to remove heat exchanger tubes from the shell Performs better than: Double jacketed metal gaskets Spiral wound gaskets Corrugated metal gaskets More reliable than PTFE joint sealants Eliminates large inventories Easier to Handle Stops damage from rough handling Doesn' t kink out of shape Adjusts to warped flanges Fills pits and scratches up to 1/ 8" deep Pressures Stainless & Inconel versions, 4500psi Carbon fiber version, low pressure services only Temperatures for temperatures over 1000 F/ 540 C, consult the factory Chemical compatibility: Consult Factory Pyro-Tex Joint Sealant HP Type: Pyro-Tex HP ( high-pressure) Joint Sealant is made from the same patented stainless-steel foil yarns as our sheet ( also available with carbon fiber reinforcement) . Available in 25 and 50 foot spools in various configurations, shapes, and thicknesses. Change gasket without pulling tube bundles Adhesive bonds in place during installation Self forms into endless gasket Made to virtually any thickness or width Never hardens or dries out Metallic reinforcement impedes extrusion Readjustable, often re-usable Individual strands reinforced with: 304 SS or Inconel foil Packaged on plastic spools Inventory just one or two sizes Eliminates the need to remove heat exchanger tubes from the shell Performs better than: Double jacketed metal gaskets Spiral wound gaskets Corrugated metal gaskets More reliable than TFE joint sealants Eliminates large inventories Easier to Handle Stops damage from rough handling Doesn' t kink out of shape Adjusts to warped flanges Fills pits and scratches up to 1/ 8" deep Pressures Stainless & Inconel versions 4500psi Temperatures ( for temperatures over 1000 F/ 540 C, consult the factory) Chemical compatibility: Consult Factory Industries Served: Steam, Nuclear, and Hydro-Electric Plants : Boiler Feed Water Boiler Recirculation Condensate Pumps Service Water Pumps River Water Intake Heater Drain Pumps Vacuum Pumps Clinker Grinders Fly-Ash Pumps Lime Slurry pumps Auxiliary Feed-Water Fire Pumps Pulp and Paper Mills: Refiners Pulpers Separators Deflakers Stock Pumps Coating Pumps Vacuum Pumps Agitators Condensate Boiler Feed Water Boiler Recirculation Liquor Pumps Continuous Digester Outlet Devices High Pressure Feeder Stock Chests PetroChemical and Oil & Gas Refineries: Hydrocarbon Pumps Residual Pumps Heat-Transfer Fluid Pumps ( Hot Oil) Bottoms Pumps Cooling Tower Pumps Steam Turbines Compressors Molten Sulphur Pumps Ammonia Pumps Paraffin Extraction Pumps Boiler Feed Pumps Condensate Pumps ( many others) Mining: Water and Slurry Pumps Boats/ Shipping: Stern Tubes ( Tail Shafts) Washdown Pumps Fire Pumps Saltwater Pumps Bilge Water Pumps Steel Manufacturing: Water and Slurry Pumps Sugar Refineries: Raw Sugar Pumps Juice Pumps Syrup Pumps Molasses Pumps Vacuum Pumps Distribution of product marketing area consists of: CV.JAVATECH-SEAL Region City of Jakarta, Bogor, Depok, Tangerang, Bekasi( JABODETABEK) and surrounding areas, Indonesia Address: Jl. Majapahit No.283, Depok II , Kota Depok, East Java Telp : 021 7710074 Fax : 021 7710074 Contac person: Mrs. Cony Esther Mobile: 081216641164 Email: techseals@ ymail.com http: / / javatechseals.indonetwork.co.id CV.Java Tech-Seal, Bandung Branch for Region Bandung City and surrounding areas, West Java, Indonesia Address : Leuwigoong 104, Kota Cimahi - Jawa Barat ( Workshop ) Contac person: Mr. Rahadian Norowiyoso S.Si Telp : 022 91791705 Mobile: 082347744243 Email: techseals@ ymail.com http: / / javatechseals.indonetwork.co.id Piramida Sakti Teknik, CV Region Yogyakarta, Solo, Semarang City and Surrounding Areas, Central Java, Indonesia Address : Perum Puri Permata no.1A, Gunung Kunci, Kartasura-Solo, Central Java Contac person: Mr.Deni Firmansyah SE.MM Phone: 0271 784350 Fax : 0271 780059 Mobile: 081808092128; 085292647770 Email : techseals@ ymail.com CV.Cahaya Seals and Gasket Region Malang City and Surrounding Areas, East Java, Indonesia Address : Sulfat Garden D10, Jl. Simp Adi Sucipto Malang 65123 Contac person: Mr.Johan Dwi Wisnu, ST Mobile: 08155522115 PT.Centra Indo Artha Region Kalimantan, Maluku, papua, and Surrounding Areas, Indonesia Address : Kompleks Ruko Mega Grosir Cempaka Mas Blok D1-30 Jl. Let Jend Suprapto, Jakarta Pusat 10640 Telp 021 42888089 Fax: 021 33342111 Contac person: Mr.Johni Mende, Mobile: 081311077763 CV.Java Tech-Seal, Luwuk Branch for Region Banggai and surrounding areas, Central Sulawesi , Indonesia Address : BTN Pepabri Luwuk Banggai- Sulawesi Tengah Contac person: Mr. Tony Samuel Mobile: 0812 1664 1164 Email: techseals@ ymail.com http: / / javatechseals.indonetwork.co.id
  • Kota Sidoarjo

Katalog Produk

TOOLS EGA MASTER

Alat Teknik Tangan Kami adalah salah satu stockiest terbesar dari semua jenis alat-alat tangan industri. Alat-alat tangan ini digunakan secara manual oleh karena itu mereka justru dirancang agar sesuai di tangan yang menyederhanakan perakitan, perbaikan, instalasi dan aplikasi industri lainnya. Kami seluruh rentang alat-alat tangan yang diproduksi mengkonfirmasikan kepada norma-norma industri yang ada sehingga memiliki pasar di seluruh dunia yang luas. Insulated Alat Organisasi kami sangat dihargai oleh klien untuk menawarkan alat Insulated. Dirancang dengan menggunakan bahan baku bermutu tinggi, alat-alat ini VDE -tested. Maskapai 1.000 volt tools & kit terisolasi diproduksi menggunakan bahan baku bermutu tinggi dan mesin canggih. Alat yang ditawarkan tersedia dalam berbagai ukuran yang sesuai dengan kebutuhan beragam klien. tool Set Dealer dan importir dari Tool Kits untuk berbagai aplikasi industri. Baik itu lokakarya atau individu, kami dapat menawarkan tool kit untuk setiap aplikasi seperti Pemeliharaan, Listrik, Plumbing, HVAC, Rail Road dan Pesawat di merek terkenal. Berbagai alat kit yang kami tawarkan adalah 1. Guru Teknisi Pemeliharaan Set 2. Teknik Mesin Tool Set 3. Alat Listrik Kit 4. Electromechanical & Pelayanan Tool Set 5. Modular Set 6. Bantalan Penarik Set 7. Railroad Jalan Mechanic Set 8. motor Mechanic Tool Set 9. HVAC Tool Set 10. Plumber Tool Set 11. Kontraktor Tool Set 12. Electrician di Tool Set

Detail Produk »

We as the main distributor of the J-FLEX RUBBER PRODUCTS, England, by selling specialised rubber sheet rubber products & component engineering, with the profile into its component parts: Seal for hydraulic-Pneumatic cylinder, flexibles consists of: Rubber Connections, Discharge socks, Gaiters, Bellows, cones , tubes, Flange sleeve, Covers, ballast bags, Vulcanised joint rings, Expansion joints, Sleeves Rubbers, gaskets, Diaphragms, washers, His material consists of: Red, White, translucent, Blue, black silicone rubber 60 ' shore, sheeting Blue FDA, FDA translucent Slicone, Milky White Fda silicone, Red Silicone Fda, Yellow Silicone Fda Rubber 60 " shore, sheeting Food Quality Translucent Silicone Rubber Sheeting 40' Shore A Silicone Rubber 10' Shore A " HTM" Light Green Thermally Conductive Silicone Sponge Closed Cell Silicone White sponge sheeting, Closed Cell Silicone white Sponge Fda. Red Iron Oxide Silicone Reinforced With 1 Ply Glass Cloth Insertion Sheet Fda. Blue ( Nearest Pantone - 2955U) Metal Detectable Silicone Sheet Fda Compliant Black gunuine DuPont Viton sheet 75 ' shore. White FDA viton sheet 65 ' Shore Nitriles / Nylon Sheet diaphragm Neoprene / Nylon diaphragm sheet Nitriles PVC / Nylon Floating Roof Tank Seals Seat Valve Blue silicone Fda, Seat Valve Red Silicone Fda, Seat Valve Milky White Silicone Fda EPDM 65 ' Shore Viton Sheet Viton sponge sheet Market Sectors including: Materials handing, Parmaceutical, Dry & Wet cement manufacturers, vibratory Motors, Offshore Oil, Food Processing, Dairy Industry, Animal feed stuffs, Agro-Chemical fertilizer, Pottery & ceramic, beverage production, Woodworking / Dust extraction, power plants, Test fasilities, marine engineering, Transportation, Environmetal Control, water engineering, textile machinery, paper machinery, Hydraulic engineering Other products that we marketed: One part caulk sealant Fluorodyn Fluorolast solvent based coating ( Self-curing type) Flurolast water borne coating ( head curable) viton rubber coated product We Al Nazeer Nippon Chemicals are the manufacturers and exporters of Elfy brand adhesives and sealants, our product range includes : 1.Super Glue 2.Silicone Sealants 3.RTV. Gasketmakers 4.Epoxy steel / clear Adhesives Pump Sealing Technology Product by Slade USA: Why Traditional Packings Fail How a Stuffing Box Should Look When Completely Packed Using Traditional Packings How a Stuffing Box Looks After Several Gland Adjustments Using Traditional Packings Traditional packings are mostly fiber with added lubricants that can be squeezed, cooked or washed out, resulting in out-of position lantern rings, over-compressed packing and sleeve wear. Slade Packed Centrifugal Pumps: Typical Stuffing Box VERSES Slade Packed Stuffing Box Typical Stuffing Box: A typical stuffing box requires leakage and/ or flush-water to dissipate heat, creating costly housekeeping problems, loss of product and/ or loss of flush-water. Additional rings cannot be added without affecting position of lantern ring. Slade Packed Stuffing Box: In most applications, a Slade packed stuffing box can be run without flush-water and/ or with virtually no leakage. In many applications, both No-Flush & No-Leak are possible! Additional rings can be added as needed. Flush-Free & Virtual Leak-Free Service slade packed stuffing boxDepending on design of equipment and speed of shaft, a permanent split bushing may be installed last ( after 3300G Rings) . Please contact us for a recommendation. Seals Rotating Equipment: Whereas most pump packings are largely abrasive fibers with added lubricants that can be squeezed, washed or cooked out, Slade 3300G utilizes the self-lubricating qualities of the very best natural, exfoliated graphite. Incorporating just enough temperature and chemical resistant  carbon fiber to make very high tensile strength yarns, Slade s patented technology allows the braided packing rings to transfer frictional heat away from high speed shaft sleeves, eliminating the need, in most cases, for cooling water. Since cooling or flushing is not typically required, there is no need for lantern rings. This eliminates the concern of the lantern rings being adjusted out of position, flush water ports becoming plugged, or sleeve wear caused by the corrosive nature of highly oxygenated water on hardened sleeves. Pump Applications For Steam, Nuclear and Hydro-Electric Plants Boiler Feed Water Boiler Recirculation Condensate Pumps Service Water Pumps River Water Intake Heater Drain Pumps Vacuum Pumps Clinker Grinders Fly-Ash Pumps Lime Slurry pumps Auxiliary Feed-Water Fire Pumps For Pulp and Paper Mills Refiners Pulpers Separators Deflakers Stock Pumps Coating Pumps Vacuum Pumps Agitators Condensate Pumps Boiler Feed Pumps Boiler Recirculation Pumps Stock Chests Mixers Steam Vessels Liquor Pumps Outlet Devices Product Information : 3300C Type: Slade s Cost Effective Pump and Valve Packing Reinforcement: Each yarn of graphite foil is reinforced with high strength structural carbon fiber Temp: Mild Oxidizers to 1800 F/ 1000 C ( for temperatures over 1000 F/ 540 C, consult the factory) Pressures: Valves to 1000 PSI/ 70 BAR ( for higher pressures, consult factory) pH Range: 1-14 3300W Type: Inconel wire reinforced for higher pressures: 5000 PSI/ 350 BAR 3300LC Type: Low chloride, high purity for nuclear service 3300LS Type: Low sulfur, high purity for nuclear service 3300G Type: Slade s Best All Purpose Pump and Valve Packing Reinforcement: Corners and yarns of graphite foil reinforced with high strength structural carbon fiber Temp: Mild Oxidizers to 1800 F/ 1000 C ( for temperatures over 1000 F/ 540 C, consult the factory) Pressures: Valves to 5000 PSI/ 350 BAR without end-rings Pumps: Flush-free in many services to 4800 FPM ( 1400 m/ min) pH Range: 1-14 Applications: Chemicals, steam, hydrocarbons, etc. Advantages: One packing inventory for all pumps and valves Works well on worn sleeves Difficult to overtighten No added lubricants to squeeze out or burn off Eliminates flush-water in most applications Not necessary to replace entire set, just add ring Won t glaze or harden Eliminates most leaks Amperage reduction of 15% is typical No special end-rings required Outlasts typical packings by factor of 6 4800 fpm/ 24 ms ( without flush water) pH 1-14 Operates virtually leak-free in most applications Low chloride/ sulfur available for nuclear service Installation: Check clearances and dimensions Best to use no more than 5 rings in stuffing box ( use Slade spacer bushings to reduce rings) Cut rings on the bias ( 45 angle) , stagger joints Compress each sealing ring at least 25% ( especially the first ring) . Do not compress spacer bushings. Loosen gland to allow it to relax Snug the gland bolts and start the pump 3300GLC Type: Low chloride for nuclear service 3300GLS Type: Low sulfur for nuclear service 3300K Type: Slades Best Triplex Pump, Reciprocating Packing Reinforcement: Same as 3300C, but with added Kevlar fiber corners Temp: Maximum temperature of 500 F/ 260 C Applications: Reciprocating/ plunger, wastewater, steam and ammonia pumps Pressures: 5000 PSI/ 350 BAR pH Range 2-12 3300CJ Type: Slade s Anti-Extrusion Carbon Fiber Packing Description: Carbon jacketed 3300C Pressures: Valves to 1000 PSI/ 70 BAR ( for higher pressures, consult factory) Application: Used as anti-extrusion end-ring 3300CJK Type: Slade s Anti-Extrusion Carbon Fiber Packing Description: 3300C with Kevlar corners Temp: 500 F/ 260 C Application: Used as end-ring to provide anti-extrusion ( especially with large throat clearances) and to provide barrier to particulate contamination Advantages: Minimizes or Virtually Eliminates Leakage! Due to its patented construction of natural, expanded graphite yarns, Slade 3300G turns the stuffing box into a heat sink, conducting heat away from shaft, in many applications, eliminating expensive leakage previously needed to cool the stuffing box. Can Be Operated Flush-Free in Most Applications Slade 3300G conducts heat away from the shaft/ sleeve, in most cases making flush unnecessary. If media has particulate contamination, a very mild flush should be all that is required. No flush-water translates into: Exceptional savings, typically 1/ 2 cent per gallon, or $ 13, 000 annually ( U.S.) ( based on 5 GPM flush system) No fear of flush-water system becoming plugged or experiencing loss of pressure Reduces Inventory and Cost By eliminating die-formed rings ( cut-rings work fine) Handles most medias, 1-14 pH, eliminating many styles of packing In many applications, no need to remove old packing, just add a ring Lasts 4 to 6 times longer than traditional pump packings Worn Shafts and Sleeves Easily Sealed Conforms to the geometry of the stuffing box and shaft. Seals most worn sleeves. Valve Sealing Technology Applications: Gate Valves Globe Valves Pinch Valves Diaphram Valves Needle Valves Plug Valves Butterfly Valves Ball Valves Check Valves Relief Valves Control Valves Knife Valves Product Selection: 3300C 3300G 3300W 3300CJ Enviro-Foil Valve Spacer Bushing Vapor Depositioned 3300G Valve Spacer Bushing Product Information 3300C Type: Slade s Cost Effective Pump and Valve Packing Reinforcement: Each yarn of graphite foil is reinforced with high strength structural carbon fiber Temp: Mild Oxidizers to 1800 F/ 1000 C ( for temperatures over 1000 F/ 540 C, consult the factory) Pressures: Valves to 1000 PSI/ 70 BAR ( for higher pressures, consult factory) pH Range: 1-14 3300W: Inconel wire reinforced for higher pressures: 5000 PSI/ 350 BAR 3300LC: Low chloride, high purity for nuclear service 3300LS: Low sulfur, high purity for nuclear service 3300G Type: Slade s Best All Purpose Pump and Valve Packing Reinforcement: Corners and yarns of graphite foil reinforced with high strength structural carbon fiber Temp: Mild Oxidizers to 1800 F/ 1000 C ( for temperatures over 1000 F/ 540 C, consult the factory) Pressures: Valves to 5000 PSI/ 350 BAR without end-rings Pumps: Flush-free in many services to 4800 FPM ( 1400 m/ min) pH Range: 1-14 Applications: Chemicals, steam, hydrocarbons, etc. Advantages Please click here to see the comprehensive list of advantages that 3300G has to offer. Installation: Check clearances and dimensions Best to use no more than 5 rings in stuffing box ( use Slade spacer bushings to reduce rings) Cut rings on the bias ( 45 angle) , stagger joints Compress each sealing ring at least 25% ( especially the first ring) . Do not compress spacer bushings. Loosen gland to allow it to relax Snug the gland bolts and start the pump 3300GLC: Low chloride for nuclear service 3300GLS: Low sulfur for nuclear service 3300W Type: Slade' s Best Valve Packing Reinforcement: Each yarn of graphite foil is reinforced with Inconel" Foil shrouded in high strength carbon fiber Temp: Mild oxidizers to 1800 F/ 1000 C ( for temperatures over 1000 F/ 540 C, consult the factory) Pressures: Up to 5, 000 psi/ 345 psi 3300CJ Type: Slade' s Anti-Extrusion Carbon Fiber Packing Description: Carbon jacketed 3300C Pressures: Valves to 1000 psi/ 70 bar ( for higher pressures, consult factory) Application: Used as anti-extrusion end ring Advantages: Fire Safe Slade braided graphite foil is API Fire Test Certified API 589 First Edition API 607 Fourth Edition ( modified by EXXON Specs) Tested by Southwest Research Institute Witnessed by 3 EXXON Engineers Temperatures to 1800 F/ 1000 C Tested at 5% of allowable standard Performed under a grant from the American Petroleum Institute Warning: Valves sealed with packings containing lubricants or blocking agents ( PTFE) may cause secondary fires when exposed to the intense heat of a fire in another unit, which would cause packing shrinkage and leakage of flammable fluids causing a secondary fire. SLADE Patented Packings: rated FIRE SAFE Emission Safe PERF Emission Standards Contact Slade for documentation EXXON-Emission Report: Emission tests, performed at a leading petroleum company' s test facility in Florham Park, NJ ( using PERF procedures and standards) , show that Slade patented, reinforced braided graphite foil outperformed standard die-formed graphite sealing rings. Slade reduced emissions by 74% . Corpus Report: A major Gulf Coast, USA refinery reports that 96% of the 325 valves packed with slade reported zero ppm emissions. Most of these valves were packed in the field by inexperienced installers. Cambridge Report: A major USA West Coast refinery reports that after 5 years, 96% of the 282 field installed valves were at zero emissions and that the 3, 000 psi hydrogen control valves never went over 9 ppm during the 5 year test. Most of these valves were packed in the field. All claims made herein are documented. GASKET: Pyro-Tex Woven Gasket Sheet Type: A resilient, compressed sheet& that works! Ready to be cut for use in severe conditions. Services: High temperatures ( for temperatures over 1000 F/ 540 C, consult the factory) High pressures ( up to 4500 psi/ 310 bar) High equipment wear ( scratches/ pores) Reinforced with Flat Metal Leaf Springs( a) of stainless steel, encapsulated in a thick vermiculated graphite foil jacket ( b) . These metal reinforced graphite strands, Slade s weaving yarns, are woven into a tough, resilient cloth-like sheet ( c) . The flat metal leaf springs at the core of each strand crisscross each other throughout the cloth to impart an enduring resiliency. The woven sheets are compressed to increase density to form a leak tight gasket sheet. Advantages Flat metallic leaf springs, jacketed with graphite foil, make this 80 x 80 sheet the most resilient gasket you will need. It takes physical abuse like no other graphite foil, handling and feeling like tough leather. The metallic spring strands are woven across one another to actuate the gasket through each thermal cycle continually adjusting to expansion and contraction that leaves other compressed gasketing lifeless ( d) . Pyro-Tex gasket sheet replaces spiral wound gaskets, removing the spiral leak path and eliminating the need for a compressing ring to prevent crushing. Pyro-Tex gasket sheet puts flanges back in compliance by filling scratches, pores, and steam cuts with flexible graphite. Each sheet is packed in heavy-duty tubes to eliminate shipping palettes and enable easy storage and handling. Gasket Types: Ring and Full Face Manhole and Handhole Diesel Exhaust Flange Manifold Combustion Engine Head Turbine Crossover Pressure Vessel Heat Exchanger Nuclear Service Gasket Standard Sizes: Gasket Special Sizes: 80 x 80 60 x 60 3/ 32 ( nominal) 80 x any length Pyro-Tex Joint Sealant Type: Slade s self-forming gasket, the Pyro-Tex Joint Sealant, is made from patented graphite-foil encapsulated carbon-fiber reinforced yarns ( also available with stainless-steel foil yarns) . This self-forming gasket when in place is compressed to fit snugly. Available in 25 and 50 foot spools in various configurations, shapes, and thicknesses. Change gasket without pulling tube bundles Adhesive bonds in place during installation Self forms into endless gasket Made to virtually any thickness or width Never hardens or dries out Metallic reinforcement impedes extrusion Readjustable, often re-usable Individual strands reinforced with: carbon fiber, 304 SS, or Inconel foil Packaged on plastic spools Inventory just one or two sizes Eliminates the need to remove heat exchanger tubes from the shell Performs better than: Double jacketed metal gaskets Spiral wound gaskets Corrugated metal gaskets More reliable than PTFE joint sealants Eliminates large inventories Easier to Handle Stops damage from rough handling Doesn' t kink out of shape Adjusts to warped flanges Fills pits and scratches up to 1/ 8" deep Pressures Stainless & Inconel versions, 4500psi Carbon fiber version, low pressure services only Temperatures for temperatures over 1000 F/ 540 C, consult the factory Chemical compatibility: Consult Factory Pyro-Tex Joint Sealant HP Type: Pyro-Tex HP ( high-pressure) Joint Sealant is made from the same patented stainless-steel foil yarns as our sheet ( also available with carbon fiber reinforcement) . Available in 25 and 50 foot spools in various configurations, shapes, and thicknesses. Change gasket without pulling tube bundles Adhesive bonds in place during installation Self forms into endless gasket Made to virtually any thickness or width Never hardens or dries out Metallic reinforcement impedes extrusion Readjustable, often re-usable Individual strands reinforced with: 304 SS or Inconel foil Packaged on plastic spools Inventory just one or two sizes Eliminates the need to remove heat exchanger tubes from the shell Performs better than: Double jacketed metal gaskets Spiral wound gaskets Corrugated metal gaskets More reliable than TFE joint sealants Eliminates large inventories Easier to Handle Stops damage from rough handling Doesn' t kink out of shape Adjusts to warped flanges Fills pits and scratches up to 1/ 8" deep Pressures Stainless & Inconel versions 4500psi Temperatures ( for temperatures over 1000 F/ 540 C, consult the factory) Chemical compatibility: Consult Factory Industries Served: Steam, Nuclear, and Hydro-Electric Plants : Boiler Feed Water Boiler Recirculation Condensate Pumps Service Water Pumps River Water Intake Heater Drain Pumps Vacuum Pumps Clinker Grinders Fly-Ash Pumps Lime Slurry pumps Auxiliary Feed-Water Fire Pumps Pulp and Paper Mills: Refiners Pulpers Separators Deflakers Stock Pumps Coating Pumps Vacuum Pumps Agitators Condensate Boiler Feed Water Boiler Recirculation Liquor Pumps Continuous Digester Outlet Devices High Pressure Feeder Stock Chests PetroChemical and Oil & Gas Refineries: Hydrocarbon Pumps Residual Pumps Heat-Transfer Fluid Pumps ( Hot Oil) Bottoms Pumps Cooling Tower Pumps Steam Turbines Compressors Molten Sulphur Pumps Ammonia Pumps Paraffin Extraction Pumps Boiler Feed Pumps Condensate Pumps ( many others) Mining: Water and Slurry Pumps Boats/ Shipping: Stern Tubes ( Tail Shafts) Washdown Pumps Fire Pumps Saltwater Pumps Bilge Water Pumps Steel Manufacturing: Water and Slurry Pumps Sugar Refineries: Raw Sugar Pumps Juice Pumps Syrup Pumps Molasses Pumps Vacuum Pumps Distribution of product marketing area consists of: CV.JAVATECH-SEAL Region City of Jakarta, Bogor, Depok, Tangerang, Bekasi( JABODETABEK) and surrounding areas, Indonesia Address: Jl. Majapahit No.283, Depok II , Kota Depok, East Java Telp : 021 7710074 Fax : 021 7710074 Contac person: Mrs. Cony Esther Mobile: 081216641164 Email: techseals@ ymail.com http: / / javatechseals.indonetwork.co.id CV.Java Tech-Seal, Bandung Branch for Region Bandung City and surrounding areas, West Java, Indonesia Address : Leuwigoong 104, Kota Cimahi - Jawa Barat ( Workshop ) Contac person: Mr. Rahadian Norowiyoso S.Si Telp : 022 91791705 Mobile: 082347744243 Email: techseals@ ymail.com http: / / javatechseals.indonetwork.co.id Piramida Sakti Teknik, CV Region Yogyakarta, Solo, Semarang City and Surrounding Areas, Central Java, Indonesia Address : Perum Puri Permata no.1A, Gunung Kunci, Kartasura-Solo, Central Java Contac person: Mr.Deni Firmansyah SE.MM Phone: 0271 784350 Fax : 0271 780059 Mobile: 081808092128; 085292647770 Email : techseals@ ymail.com CV.Cahaya Seals and Gasket Region Malang City and Surrounding Areas, East Java, Indonesia Address : Sulfat Garden D10, Jl. Simp Adi Sucipto Malang 65123 Contac person: Mr.Johan Dwi Wisnu, ST Mobile: 08155522115 PT.Centra Indo Artha Region Kalimantan, Maluku, papua, and Surrounding Areas, Indonesia Address : Kompleks Ruko Mega Grosir Cempaka Mas Blok D1-30 Jl. Let Jend Suprapto, Jakarta Pusat 10640 Telp 021 42888089 Fax: 021 33342111 Contac person: Mr.Johni Mende, Mobile: 081311077763 CV.Java Tech-Seal, Luwuk Branch for Region Banggai and surrounding areas, Central Sulawesi , Indonesia Address : BTN Pepabri Luwuk Banggai- Sulawesi Tengah Contac person: Mr. Tony Samuel Mobile: 0812 1664 1164 Email: techseals@ ymail.com http: / / javatechseals.indonetwork.co.id
  • Kota Sidoarjo

Katalog Produk

FLANGED

Flange adalah sebuah punggungan eksternal maupun internal , atau pinggiran ( bibir ) , untuk kekuatan , sebagai flange dari sinar besi seperti balok-I atau T -beam , atau untuk lampiran ke obyek lain , seperti flange pada akhir dari pipa , silinder uap , dll , atau pada mount lensa kamera , atau untuk flens mobil rel atau roda trem . Dengan demikian roda bergelang adalah roda dengan flens di satu sisi untuk menjaga roda dari berjalan dari rel . Istilah " flange " juga digunakan untuk jenis alat yang digunakan untuk membentuk flensa . Pipa dengan flensa dapat dirakit dan dibongkar dengan mudah . Ada banyak standar flange yang berbeda dapat ditemukan di seluruh dunia . Untuk memungkinkan fungsi mudah dan antar - berubah-ubah , ini dirancang memiliki dimensi standar . Standar dunia umum meliputi ASA / ANSI / ASME ( USA ) , PN / DIN ( Eropa ) , BS10 ( Inggris / Australia ) , dan JIS / KS ( Jepang / Korea ) . Dalam kebanyakan kasus ini tidak bisa saling ( misalnya ANSI / ASME flange tidak akan kawin terhadap flange JIS ) . Selanjutnya , banyak dari flensa di setiap standar dibagi menjadi " kelas tekanan " , yang memungkinkan flensa harus mampu mengambil peringkat tekanan yang berbeda . Sekali lagi ini umumnya tidak saling dipertukarkan ( misalnya ANSI / ASME 150 tidak akan kawin dengan ANSI / ASME 300 ) . Kelas-kelas tekanan juga tekanan dan suhu peringkat yang berbeda untuk bahan yang berbeda . Kelas tekanan yang unik untuk pipa juga dapat dikembangkan untuk pembangkit proses atau stasiun pembangkit listrik , ini mungkin khusus untuk korporasi , pengadaan rekayasa dan konstruksi ( EPC ) kontraktor , atau pemilik pabrik pengolahan. Kelas-kelas tekanan ANSI / ASME untuk Flat - Wajah flens adalah 125 # dan 250 # . Kelas-kelas untuk Ring - Joint , Tongue & Groove , dan Dibesarkan - Wajah flens 150 # , 300 # , ( 400 # - biasa ) , 600 # , 900 # , 1500 # , dan 2500 # . Wajah-wajah flange juga dibuat dengan dimensi standar dan biasanya " wajah datar " , " mengangkat wajah" , " lidah dan alur " , atau " cincin bersama" gaya , meskipun gaya jelas lain yang mungkin. Desain Flange tersedia sebagai " las leher " , " slip-on " , " lap bersama" , " soket las " , " ulir " , dan juga " buta " . ASME standar ( AS) ASME jenis flange pada pipa gas Pipa flensa yang dibuat dengan standar yang disebut oleh ASME B16.5 atau ASME B16.47 biasanya terbuat dari bahan ditempa dan memiliki permukaan mesin . B16.5 mengacu pada ukuran pipa nominal ( NPS ) dari ½ " sampai 24 " . B16.47 mencakup NPSs dari 26 " sampai 60 " . Setiap spesifikasi lebih lanjut melukiskan flensa ke dalam kelas tekanan : 150 , 300 , 400 , 600 , 900 , 1500 dan 2500 psi untuk B16.5 , B16.47 delineates yang flensa ke dalam kelas tekanan 75 , 150 , 300 , 400 , 600 , 900 . Jenis gasket dan jenis baut umumnya ditentukan oleh standar ( s ) , namun kadang-kadang mengacu pada standar ASME Boiler dan Pressure Vessel Kode ( B & PVC ) untuk rincian ( lihat ASME Kode Bagian VIII Divisi 1 - Lampiran 2 ) . Ini flensa diakui oleh ASME Pipa Kode ASME B31.1 seperti Daya Piping , dan ASME B31.3 Process Piping . Bahan untuk flensa biasanya di bawah ASME penunjukan : SA - 105 ( Spesifikasi Carbon Steel Tempa untuk Aplikasi Piping ) , SA - 266 ( Spesifikasi Carbon Steel Tempa untuk Bejana Komponen ) , atau SA - 182 ( Spesifikasi Forged atau Rolled Alloy - steel Pipe Flange , Fittings Ditempa , dan Katup dan Bagian untuk Layanan High - Temperature ) . Selain itu, ada banyak " standar industri " flensa bahwa dalam beberapa keadaan dapat digunakan pada pekerjaan ASME .Ada banyak standar flange yang berbeda dapat ditemukan di seluruh dunia . Untuk memungkinkan fungsi mudah dan antar - berubah-ubah , ini dirancang memiliki dimensi standar . Standar dunia umum meliputi ASA / ANSI / ASME ( USA ) , PN / DIN ( Eropa ) , BS10 ( Inggris / Australia ) , dan JIS / KS ( Jepang / Korea ) . Dalam kebanyakan kasus ini tidak bisa saling ( misalnya ANSI / ASME flange tidak akan kawin terhadap flange JIS ) . Selanjutnya , banyak dari flensa di setiap standar dibagi menjadi " kelas tekanan " , yang memungkinkan flensa harus mampu mengambil peringkat tekanan yang berbeda . Sekali lagi ini umumnya tidak saling dipertukarkan ( misalnya ANSI / ASME 150 tidak akan kawin dengan ANSI / ASME 300 ) . Kelas-kelas tekanan juga tekanan dan suhu peringkat yang berbeda untuk bahan yang berbeda . Kelas tekanan yang unik untuk pipa juga dapat dikembangkan untuk pembangkit proses atau stasiun pembangkit listrik , ini mungkin khusus untuk korporasi , pengadaan rekayasa dan konstruksi ( EPC ) kontraktor , atau pemilik pabrik pengolahan. Kelas-kelas tekanan ANSI / ASME untuk Flat - Wajah flens adalah 125 # dan 250 # . Kelas-kelas untuk Ring - Joint , Tongue & Groove , dan Dibesarkan - Wajah flens 150 # , 300 # , ( 400 # - biasa ) , 600 # , 900 # , 1500 # , dan 2500 # . Wajah-wajah flange juga dibuat dengan dimensi standar dan biasanya " wajah datar " , " mengangkat wajah" , " lidah dan alur " , atau " cincin bersama" gaya , meskipun gaya jelas lain yang mungkin. Desain Flange tersedia sebagai " las leher " , " slip-on " , " lap bersama" , " soket las " , " ulir " , dan juga " buta " . ASME standar ( AS) ASME jenis flange pada pipa gas Pipa flensa yang dibuat dengan standar yang disebut oleh ASME B16.5 atau ASME B16.47 biasanya terbuat dari bahan ditempa dan memiliki permukaan mesin . B16.5 mengacu pada ukuran pipa nominal ( NPS ) dari ½ " sampai 24 " . B16.47 mencakup NPSs dari 26 " sampai 60 " . Setiap spesifikasi lebih lanjut melukiskan flensa ke dalam kelas tekanan : 150 , 300 , 400 , 600 , 900 , 1500 dan 2500 psi untuk B16.5 , B16.47 delineates yang flensa ke dalam kelas tekanan 75 , 150 , 300 , 400 , 600 , 900 . Jenis gasket dan jenis baut umumnya ditentukan oleh standar ( s ) , namun kadang-kadang mengacu pada standar ASME Boiler dan Pressure Vessel Kode ( B & PVC ) untuk rincian ( lihat ASME Kode Bagian VIII Divisi 1 - Lampiran 2 ) . Ini flensa diakui oleh ASME Pipa Kode ASME B31.1 seperti Daya Piping , dan ASME B31.3 Process Piping . Bahan untuk flensa biasanya di bawah ASME penunjukan : SA - 105 ( Spesifikasi Carbon Steel Tempa untuk Aplikasi Piping ) , SA - 266 ( Spesifikasi Carbon Steel Tempa untuk Bejana Komponen ) , atau SA - 182 ( Spesifikasi Forged atau Rolled Alloy - steel Pipe Flange , Fittings Ditempa , dan Katup dan Bagian untuk Layanan High - Temperature ) . Selain itu, ada banyak " standar industri " flensa bahwa dalam beberapa keadaan dapat digunakan pada pekerjaan ASME .

Detail Produk »

We as the main distributor of the J-FLEX RUBBER PRODUCTS, England, by selling specialised rubber sheet rubber products & component engineering, with the profile into its component parts: Seal for hydraulic-Pneumatic cylinder, flexibles consists of: Rubber Connections, Discharge socks, Gaiters, Bellows, cones , tubes, Flange sleeve, Covers, ballast bags, Vulcanised joint rings, Expansion joints, Sleeves Rubbers, gaskets, Diaphragms, washers, His material consists of: Red, White, translucent, Blue, black silicone rubber 60 ' shore, sheeting Blue FDA, FDA translucent Slicone, Milky White Fda silicone, Red Silicone Fda, Yellow Silicone Fda Rubber 60 " shore, sheeting Food Quality Translucent Silicone Rubber Sheeting 40' Shore A Silicone Rubber 10' Shore A " HTM" Light Green Thermally Conductive Silicone Sponge Closed Cell Silicone White sponge sheeting, Closed Cell Silicone white Sponge Fda. Red Iron Oxide Silicone Reinforced With 1 Ply Glass Cloth Insertion Sheet Fda. Blue ( Nearest Pantone - 2955U) Metal Detectable Silicone Sheet Fda Compliant Black gunuine DuPont Viton sheet 75 ' shore. White FDA viton sheet 65 ' Shore Nitriles / Nylon Sheet diaphragm Neoprene / Nylon diaphragm sheet Nitriles PVC / Nylon Floating Roof Tank Seals Seat Valve Blue silicone Fda, Seat Valve Red Silicone Fda, Seat Valve Milky White Silicone Fda EPDM 65 ' Shore Viton Sheet Viton sponge sheet Market Sectors including: Materials handing, Parmaceutical, Dry & Wet cement manufacturers, vibratory Motors, Offshore Oil, Food Processing, Dairy Industry, Animal feed stuffs, Agro-Chemical fertilizer, Pottery & ceramic, beverage production, Woodworking / Dust extraction, power plants, Test fasilities, marine engineering, Transportation, Environmetal Control, water engineering, textile machinery, paper machinery, Hydraulic engineering Other products that we marketed: One part caulk sealant Fluorodyn Fluorolast solvent based coating ( Self-curing type) Flurolast water borne coating ( head curable) viton rubber coated product We Al Nazeer Nippon Chemicals are the manufacturers and exporters of Elfy brand adhesives and sealants, our product range includes : 1.Super Glue 2.Silicone Sealants 3.RTV. Gasketmakers 4.Epoxy steel / clear Adhesives Pump Sealing Technology Product by Slade USA: Why Traditional Packings Fail How a Stuffing Box Should Look When Completely Packed Using Traditional Packings How a Stuffing Box Looks After Several Gland Adjustments Using Traditional Packings Traditional packings are mostly fiber with added lubricants that can be squeezed, cooked or washed out, resulting in out-of position lantern rings, over-compressed packing and sleeve wear. Slade Packed Centrifugal Pumps: Typical Stuffing Box VERSES Slade Packed Stuffing Box Typical Stuffing Box: A typical stuffing box requires leakage and/ or flush-water to dissipate heat, creating costly housekeeping problems, loss of product and/ or loss of flush-water. Additional rings cannot be added without affecting position of lantern ring. Slade Packed Stuffing Box: In most applications, a Slade packed stuffing box can be run without flush-water and/ or with virtually no leakage. In many applications, both No-Flush & No-Leak are possible! Additional rings can be added as needed. Flush-Free & Virtual Leak-Free Service slade packed stuffing boxDepending on design of equipment and speed of shaft, a permanent split bushing may be installed last ( after 3300G Rings) . Please contact us for a recommendation. Seals Rotating Equipment: Whereas most pump packings are largely abrasive fibers with added lubricants that can be squeezed, washed or cooked out, Slade 3300G utilizes the self-lubricating qualities of the very best natural, exfoliated graphite. Incorporating just enough temperature and chemical resistant  carbon fiber to make very high tensile strength yarns, Slade s patented technology allows the braided packing rings to transfer frictional heat away from high speed shaft sleeves, eliminating the need, in most cases, for cooling water. Since cooling or flushing is not typically required, there is no need for lantern rings. This eliminates the concern of the lantern rings being adjusted out of position, flush water ports becoming plugged, or sleeve wear caused by the corrosive nature of highly oxygenated water on hardened sleeves. Pump Applications For Steam, Nuclear and Hydro-Electric Plants Boiler Feed Water Boiler Recirculation Condensate Pumps Service Water Pumps River Water Intake Heater Drain Pumps Vacuum Pumps Clinker Grinders Fly-Ash Pumps Lime Slurry pumps Auxiliary Feed-Water Fire Pumps For Pulp and Paper Mills Refiners Pulpers Separators Deflakers Stock Pumps Coating Pumps Vacuum Pumps Agitators Condensate Pumps Boiler Feed Pumps Boiler Recirculation Pumps Stock Chests Mixers Steam Vessels Liquor Pumps Outlet Devices Product Information : 3300C Type: Slade s Cost Effective Pump and Valve Packing Reinforcement: Each yarn of graphite foil is reinforced with high strength structural carbon fiber Temp: Mild Oxidizers to 1800 F/ 1000 C ( for temperatures over 1000 F/ 540 C, consult the factory) Pressures: Valves to 1000 PSI/ 70 BAR ( for higher pressures, consult factory) pH Range: 1-14 3300W Type: Inconel wire reinforced for higher pressures: 5000 PSI/ 350 BAR 3300LC Type: Low chloride, high purity for nuclear service 3300LS Type: Low sulfur, high purity for nuclear service 3300G Type: Slade s Best All Purpose Pump and Valve Packing Reinforcement: Corners and yarns of graphite foil reinforced with high strength structural carbon fiber Temp: Mild Oxidizers to 1800 F/ 1000 C ( for temperatures over 1000 F/ 540 C, consult the factory) Pressures: Valves to 5000 PSI/ 350 BAR without end-rings Pumps: Flush-free in many services to 4800 FPM ( 1400 m/ min) pH Range: 1-14 Applications: Chemicals, steam, hydrocarbons, etc. Advantages: One packing inventory for all pumps and valves Works well on worn sleeves Difficult to overtighten No added lubricants to squeeze out or burn off Eliminates flush-water in most applications Not necessary to replace entire set, just add ring Won t glaze or harden Eliminates most leaks Amperage reduction of 15% is typical No special end-rings required Outlasts typical packings by factor of 6 4800 fpm/ 24 ms ( without flush water) pH 1-14 Operates virtually leak-free in most applications Low chloride/ sulfur available for nuclear service Installation: Check clearances and dimensions Best to use no more than 5 rings in stuffing box ( use Slade spacer bushings to reduce rings) Cut rings on the bias ( 45 angle) , stagger joints Compress each sealing ring at least 25% ( especially the first ring) . Do not compress spacer bushings. Loosen gland to allow it to relax Snug the gland bolts and start the pump 3300GLC Type: Low chloride for nuclear service 3300GLS Type: Low sulfur for nuclear service 3300K Type: Slades Best Triplex Pump, Reciprocating Packing Reinforcement: Same as 3300C, but with added Kevlar fiber corners Temp: Maximum temperature of 500 F/ 260 C Applications: Reciprocating/ plunger, wastewater, steam and ammonia pumps Pressures: 5000 PSI/ 350 BAR pH Range 2-12 3300CJ Type: Slade s Anti-Extrusion Carbon Fiber Packing Description: Carbon jacketed 3300C Pressures: Valves to 1000 PSI/ 70 BAR ( for higher pressures, consult factory) Application: Used as anti-extrusion end-ring 3300CJK Type: Slade s Anti-Extrusion Carbon Fiber Packing Description: 3300C with Kevlar corners Temp: 500 F/ 260 C Application: Used as end-ring to provide anti-extrusion ( especially with large throat clearances) and to provide barrier to particulate contamination Advantages: Minimizes or Virtually Eliminates Leakage! Due to its patented construction of natural, expanded graphite yarns, Slade 3300G turns the stuffing box into a heat sink, conducting heat away from shaft, in many applications, eliminating expensive leakage previously needed to cool the stuffing box. Can Be Operated Flush-Free in Most Applications Slade 3300G conducts heat away from the shaft/ sleeve, in most cases making flush unnecessary. If media has particulate contamination, a very mild flush should be all that is required. No flush-water translates into: Exceptional savings, typically 1/ 2 cent per gallon, or $ 13, 000 annually ( U.S.) ( based on 5 GPM flush system) No fear of flush-water system becoming plugged or experiencing loss of pressure Reduces Inventory and Cost By eliminating die-formed rings ( cut-rings work fine) Handles most medias, 1-14 pH, eliminating many styles of packing In many applications, no need to remove old packing, just add a ring Lasts 4 to 6 times longer than traditional pump packings Worn Shafts and Sleeves Easily Sealed Conforms to the geometry of the stuffing box and shaft. Seals most worn sleeves. Valve Sealing Technology Applications: Gate Valves Globe Valves Pinch Valves Diaphram Valves Needle Valves Plug Valves Butterfly Valves Ball Valves Check Valves Relief Valves Control Valves Knife Valves Product Selection: 3300C 3300G 3300W 3300CJ Enviro-Foil Valve Spacer Bushing Vapor Depositioned 3300G Valve Spacer Bushing Product Information 3300C Type: Slade s Cost Effective Pump and Valve Packing Reinforcement: Each yarn of graphite foil is reinforced with high strength structural carbon fiber Temp: Mild Oxidizers to 1800 F/ 1000 C ( for temperatures over 1000 F/ 540 C, consult the factory) Pressures: Valves to 1000 PSI/ 70 BAR ( for higher pressures, consult factory) pH Range: 1-14 3300W: Inconel wire reinforced for higher pressures: 5000 PSI/ 350 BAR 3300LC: Low chloride, high purity for nuclear service 3300LS: Low sulfur, high purity for nuclear service 3300G Type: Slade s Best All Purpose Pump and Valve Packing Reinforcement: Corners and yarns of graphite foil reinforced with high strength structural carbon fiber Temp: Mild Oxidizers to 1800 F/ 1000 C ( for temperatures over 1000 F/ 540 C, consult the factory) Pressures: Valves to 5000 PSI/ 350 BAR without end-rings Pumps: Flush-free in many services to 4800 FPM ( 1400 m/ min) pH Range: 1-14 Applications: Chemicals, steam, hydrocarbons, etc. Advantages Please click here to see the comprehensive list of advantages that 3300G has to offer. Installation: Check clearances and dimensions Best to use no more than 5 rings in stuffing box ( use Slade spacer bushings to reduce rings) Cut rings on the bias ( 45 angle) , stagger joints Compress each sealing ring at least 25% ( especially the first ring) . Do not compress spacer bushings. Loosen gland to allow it to relax Snug the gland bolts and start the pump 3300GLC: Low chloride for nuclear service 3300GLS: Low sulfur for nuclear service 3300W Type: Slade' s Best Valve Packing Reinforcement: Each yarn of graphite foil is reinforced with Inconel" Foil shrouded in high strength carbon fiber Temp: Mild oxidizers to 1800 F/ 1000 C ( for temperatures over 1000 F/ 540 C, consult the factory) Pressures: Up to 5, 000 psi/ 345 psi 3300CJ Type: Slade' s Anti-Extrusion Carbon Fiber Packing Description: Carbon jacketed 3300C Pressures: Valves to 1000 psi/ 70 bar ( for higher pressures, consult factory) Application: Used as anti-extrusion end ring Advantages: Fire Safe Slade braided graphite foil is API Fire Test Certified API 589 First Edition API 607 Fourth Edition ( modified by EXXON Specs) Tested by Southwest Research Institute Witnessed by 3 EXXON Engineers Temperatures to 1800 F/ 1000 C Tested at 5% of allowable standard Performed under a grant from the American Petroleum Institute Warning: Valves sealed with packings containing lubricants or blocking agents ( PTFE) may cause secondary fires when exposed to the intense heat of a fire in another unit, which would cause packing shrinkage and leakage of flammable fluids causing a secondary fire. SLADE Patented Packings: rated FIRE SAFE Emission Safe PERF Emission Standards Contact Slade for documentation EXXON-Emission Report: Emission tests, performed at a leading petroleum company' s test facility in Florham Park, NJ ( using PERF procedures and standards) , show that Slade patented, reinforced braided graphite foil outperformed standard die-formed graphite sealing rings. Slade reduced emissions by 74% . Corpus Report: A major Gulf Coast, USA refinery reports that 96% of the 325 valves packed with slade reported zero ppm emissions. Most of these valves were packed in the field by inexperienced installers. Cambridge Report: A major USA West Coast refinery reports that after 5 years, 96% of the 282 field installed valves were at zero emissions and that the 3, 000 psi hydrogen control valves never went over 9 ppm during the 5 year test. Most of these valves were packed in the field. All claims made herein are documented. GASKET: Pyro-Tex Woven Gasket Sheet Type: A resilient, compressed sheet& that works! Ready to be cut for use in severe conditions. Services: High temperatures ( for temperatures over 1000 F/ 540 C, consult the factory) High pressures ( up to 4500 psi/ 310 bar) High equipment wear ( scratches/ pores) Reinforced with Flat Metal Leaf Springs( a) of stainless steel, encapsulated in a thick vermiculated graphite foil jacket ( b) . These metal reinforced graphite strands, Slade s weaving yarns, are woven into a tough, resilient cloth-like sheet ( c) . The flat metal leaf springs at the core of each strand crisscross each other throughout the cloth to impart an enduring resiliency. The woven sheets are compressed to increase density to form a leak tight gasket sheet. Advantages Flat metallic leaf springs, jacketed with graphite foil, make this 80 x 80 sheet the most resilient gasket you will need. It takes physical abuse like no other graphite foil, handling and feeling like tough leather. The metallic spring strands are woven across one another to actuate the gasket through each thermal cycle continually adjusting to expansion and contraction that leaves other compressed gasketing lifeless ( d) . Pyro-Tex gasket sheet replaces spiral wound gaskets, removing the spiral leak path and eliminating the need for a compressing ring to prevent crushing. Pyro-Tex gasket sheet puts flanges back in compliance by filling scratches, pores, and steam cuts with flexible graphite. Each sheet is packed in heavy-duty tubes to eliminate shipping palettes and enable easy storage and handling. Gasket Types: Ring and Full Face Manhole and Handhole Diesel Exhaust Flange Manifold Combustion Engine Head Turbine Crossover Pressure Vessel Heat Exchanger Nuclear Service Gasket Standard Sizes: Gasket Special Sizes: 80 x 80 60 x 60 3/ 32 ( nominal) 80 x any length Pyro-Tex Joint Sealant Type: Slade s self-forming gasket, the Pyro-Tex Joint Sealant, is made from patented graphite-foil encapsulated carbon-fiber reinforced yarns ( also available with stainless-steel foil yarns) . This self-forming gasket when in place is compressed to fit snugly. Available in 25 and 50 foot spools in various configurations, shapes, and thicknesses. Change gasket without pulling tube bundles Adhesive bonds in place during installation Self forms into endless gasket Made to virtually any thickness or width Never hardens or dries out Metallic reinforcement impedes extrusion Readjustable, often re-usable Individual strands reinforced with: carbon fiber, 304 SS, or Inconel foil Packaged on plastic spools Inventory just one or two sizes Eliminates the need to remove heat exchanger tubes from the shell Performs better than: Double jacketed metal gaskets Spiral wound gaskets Corrugated metal gaskets More reliable than PTFE joint sealants Eliminates large inventories Easier to Handle Stops damage from rough handling Doesn' t kink out of shape Adjusts to warped flanges Fills pits and scratches up to 1/ 8" deep Pressures Stainless & Inconel versions, 4500psi Carbon fiber version, low pressure services only Temperatures for temperatures over 1000 F/ 540 C, consult the factory Chemical compatibility: Consult Factory Pyro-Tex Joint Sealant HP Type: Pyro-Tex HP ( high-pressure) Joint Sealant is made from the same patented stainless-steel foil yarns as our sheet ( also available with carbon fiber reinforcement) . Available in 25 and 50 foot spools in various configurations, shapes, and thicknesses. Change gasket without pulling tube bundles Adhesive bonds in place during installation Self forms into endless gasket Made to virtually any thickness or width Never hardens or dries out Metallic reinforcement impedes extrusion Readjustable, often re-usable Individual strands reinforced with: 304 SS or Inconel foil Packaged on plastic spools Inventory just one or two sizes Eliminates the need to remove heat exchanger tubes from the shell Performs better than: Double jacketed metal gaskets Spiral wound gaskets Corrugated metal gaskets More reliable than TFE joint sealants Eliminates large inventories Easier to Handle Stops damage from rough handling Doesn' t kink out of shape Adjusts to warped flanges Fills pits and scratches up to 1/ 8" deep Pressures Stainless & Inconel versions 4500psi Temperatures ( for temperatures over 1000 F/ 540 C, consult the factory) Chemical compatibility: Consult Factory Industries Served: Steam, Nuclear, and Hydro-Electric Plants : Boiler Feed Water Boiler Recirculation Condensate Pumps Service Water Pumps River Water Intake Heater Drain Pumps Vacuum Pumps Clinker Grinders Fly-Ash Pumps Lime Slurry pumps Auxiliary Feed-Water Fire Pumps Pulp and Paper Mills: Refiners Pulpers Separators Deflakers Stock Pumps Coating Pumps Vacuum Pumps Agitators Condensate Boiler Feed Water Boiler Recirculation Liquor Pumps Continuous Digester Outlet Devices High Pressure Feeder Stock Chests PetroChemical and Oil & Gas Refineries: Hydrocarbon Pumps Residual Pumps Heat-Transfer Fluid Pumps ( Hot Oil) Bottoms Pumps Cooling Tower Pumps Steam Turbines Compressors Molten Sulphur Pumps Ammonia Pumps Paraffin Extraction Pumps Boiler Feed Pumps Condensate Pumps ( many others) Mining: Water and Slurry Pumps Boats/ Shipping: Stern Tubes ( Tail Shafts) Washdown Pumps Fire Pumps Saltwater Pumps Bilge Water Pumps Steel Manufacturing: Water and Slurry Pumps Sugar Refineries: Raw Sugar Pumps Juice Pumps Syrup Pumps Molasses Pumps Vacuum Pumps Distribution of product marketing area consists of: CV.JAVATECH-SEAL Region City of Jakarta, Bogor, Depok, Tangerang, Bekasi( JABODETABEK) and surrounding areas, Indonesia Address: Jl. Majapahit No.283, Depok II , Kota Depok, East Java Telp : 021 7710074 Fax : 021 7710074 Contac person: Mrs. Cony Esther Mobile: 081216641164 Email: techseals@ ymail.com http: / / javatechseals.indonetwork.co.id CV.Java Tech-Seal, Bandung Branch for Region Bandung City and surrounding areas, West Java, Indonesia Address : Leuwigoong 104, Kota Cimahi - Jawa Barat ( Workshop ) Contac person: Mr. Rahadian Norowiyoso S.Si Telp : 022 91791705 Mobile: 082347744243 Email: techseals@ ymail.com http: / / javatechseals.indonetwork.co.id Piramida Sakti Teknik, CV Region Yogyakarta, Solo, Semarang City and Surrounding Areas, Central Java, Indonesia Address : Perum Puri Permata no.1A, Gunung Kunci, Kartasura-Solo, Central Java Contac person: Mr.Deni Firmansyah SE.MM Phone: 0271 784350 Fax : 0271 780059 Mobile: 081808092128; 085292647770 Email : techseals@ ymail.com CV.Cahaya Seals and Gasket Region Malang City and Surrounding Areas, East Java, Indonesia Address : Sulfat Garden D10, Jl. Simp Adi Sucipto Malang 65123 Contac person: Mr.Johan Dwi Wisnu, ST Mobile: 08155522115 PT.Centra Indo Artha Region Kalimantan, Maluku, papua, and Surrounding Areas, Indonesia Address : Kompleks Ruko Mega Grosir Cempaka Mas Blok D1-30 Jl. Let Jend Suprapto, Jakarta Pusat 10640 Telp 021 42888089 Fax: 021 33342111 Contac person: Mr.Johni Mende, Mobile: 081311077763 CV.Java Tech-Seal, Luwuk Branch for Region Banggai and surrounding areas, Central Sulawesi , Indonesia Address : BTN Pepabri Luwuk Banggai- Sulawesi Tengah Contac person: Mr. Tony Samuel Mobile: 0812 1664 1164 Email: techseals@ ymail.com http: / / javatechseals.indonetwork.co.id
  • Kota Sidoarjo
